Airtac HFCQ Hollow Type Pneumatic Gripper HFCQ32
1. Integrated hollow tube design enables blow-off functionality for chip removal applications.
2. Precision-crafted jaw piston rods manufactured from premium stainless steel deliver exceptional strength, corrosion resistance, and minimized assembly clearance with reduced wobble for enhanced durability.
3. Standard protective bellows ensure reliable operation in demanding environments, including specialized industrial conditions.
4. Base-mounted locating pin holes optimize mounting accuracy and maintain positional consistency through repeated installation cycles.
5. Tail-end ejector mechanism compatibility enables integrated workpiece ejection functionality.
6. Universal sensor groove design facilitates multi-specification sensor integration.
Category: Parallel Grippers | Brand: AirTAC | Series: HFCQ
AirTAC HFCQ32 Hollow Type Pneumatic Gripper Specifications
- Model: HFCQ32
- Type: Hollow parallel gripper (double-acting)
- Gripping force: 54N (parallel grip) / 43N (swing grip)
- Bore size: Ø16mm through-hole diameter
- Operating pressure: 0.1–0.7 MPa
- Material: Aluminum alloy body with NBR seals
- Stroke options: 15mm standard (customizable 5-30mm)
- Repeat accuracy: ±0.05mm
- Temperature range: -10℃ to 70℃
- Weight: ~450g (without fittings)
- Dimensions: 105mm(L) × 32mm(W) × 32mm(H)
- Port size: M5×0.8 (1/8" NPT optional)
- Shock resistance: 10m/s² max
- Protection rating: IP54
- Max operating speed: 500mm/s
The HFCQ32 features a unique hollow channel design allowing internal routing of cables/pneumatic lines through the gripper center. Its dual-guide rail structure ensures precise parallel motion with minimal angular deviation. The Type III hard anodized surface treatment enhances wear resistance in continuous operation.
- Robotic arm tool changers with integrated utilities
- PCB handling in electronics assembly lines
- Bottle cap sorting with internal vacuum pickup
- Medical device assembly requiring clean cable management
- Automated packaging systems with through-tool air jets
Installation note:
Maintain 0.5-1mm clearance between jaws and workpiece during initial alignment.
Use precision gauge pins for parallel calibration. Lubricate guide rails every
500,000 cycles with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | HFCQ32 |
| Operation Type | Double Acting |
| Port Size | M5×0.8 |
| Actuator Mechanism | None |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <32 mm> |
