Airtac SCT80~100 Multi-Position Tandem Cylinder SCT80X100X100S
2. Features specialized bidirectional sealing profile for pistons with compact dimensions and oil reservoir integration;
3. Tie-rod structure with pillar-connected end caps and aluminum alloy barrel ensures superior reliability;
4. Enables multi-position rod locking throughout the full stroke range;
5. Precision-adjustable pneumatic cushioning for smooth operation;
6. Configurable with multiple bore sizes and mounting accessories;
7. High-temperature resistant seals support operational range of 0-150°C.
Category: Multi-Position Force Amplifying Cylinders | Brand: AirTAC | Series: SCT80~100
AirTAC SCT80X100X100S Multi-Position Tandem Cylinder Specifications
- Model: SCT80X100X100S
- Type: Multi-position tandem cylinder (2-3 position configurations)
- Bore size: 80mm
- Stroke: 100mm + 100mm (dual-stage)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Mounting style: Standard ISO/VDMA front flange
- Cushioning: Adjustable elastic cushion (both ends)
- Repeat positioning accuracy: ±0.5mm
- Port size: G1/2 (NPT1/2 optional)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU hybrid seals
- Weight: 8.5kg (without accessories)
- Dimensions: 300mm(L) × 110mm(W) × 110mm(H)
- Protection rating: IP54 (standard), IP67 (optional)
High-rigidity tandem cylinder with integrated multi-position control capability, featuring dual-piston synchronization technology for precision multi-point positioning. The staggered piston design reduces lateral torque by 30% compared to conventional models. Includes wear-compensation seals and anti-rotation guidance system for heavy-duty cycles.
- Automated welding fixture positioning systems
- Injection molding machine core-pull mechanisms
- PCB handling robots with intermediate stops
- Automotive assembly line pallet locking stations
- Glass tempering oven door actuation systems
Installation note:
Requires minimum 5μm filtration with automatic lubrication (ISO VG32 recommended).
Maximum side load capacity: 450N at mid-stroke. For vertical mounting,
use auxiliary rod-end support brackets (ASF80-200 accessory kit recommended).
| Property | Property Value |
|---|---|
| sku | SCT80X100X100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
| Stroke | 100mm |
