Airtac SCT80~100 Multi-Position Tandem Cylinder SCT80X100X50S
2. Features specialized bidirectional sealing profile for pistons with compact dimensions and oil reservoir integration;
3. Tie-rod structure with pillar-connected end caps and aluminum alloy barrel ensures superior reliability;
4. Enables multi-position rod locking throughout the full stroke range;
5. Precision-adjustable pneumatic cushioning for smooth operation;
6. Configurable with multiple bore sizes and mounting accessories;
7. High-temperature resistant seals support operational range of 0-150°C.
Category: Multi-Position Force Amplifying Cylinders | Brand: AirTAC | Series: SCT80~100
AirTAC SCT80X100X50S Multi-Position Force Amplifier Cylinder Specifications
- Full model: SCT80X100X50S
- Series range: SCT80~100
- Bore size: 80mm
- Stroke: 100mm
- Stage configuration: 3-stage force amplification (50S designation)
- Operating pressure: 0.1-0.9 MPa
- Max thrust force: 5,800N @0.7MPa
- Mounting type: Standard MF1 flange
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seal type: NBR with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Repeat positioning accuracy: ±0.2mm
- Port size: 1/4 NPT (G1/4 optional)
- Max speed: 1.5 m/s
- Lubrication: Pre-lubricated (ISO VG32 recommended)
- Weight: 2.8kg (without accessories)
- Dimensions: 330mm(L) × 80mm(W) × 80mm(H)
Multi-chamber force amplifier cylinder with synchronized positioning capability, featuring triple-stage pressure intensification for precision force control. Integrated magnetic piston enables position feedback when used with sensors. Anti-rotation design maintains orientation during complex motion sequences.
- Automotive assembly line component pressing
- Die-casting machine ejection systems
- PCB lamination equipment
- High-torque clamping fixtures
- Packaging machine sealing head actuation
Installation guidelines:
Maintain parallel alignment with driven components. Requires filtered (5μm)
dry air supply. Lubricator recommended for extended service intervals (8,000km stroke).
Avoid side loads exceeding 30N.
Maximum allowable misalignment: ±0.5°. For vertical mounting,
use counterbalance valves for controlled descent.
| Property | Property Value |
|---|---|
| sku | SCT80X100X50S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
| Stroke | <50mm> |
