Airtac SCT80~100 Multi-Position Tandem Cylinder SCT80X10X10
2. Features specialized bidirectional sealing profile for pistons with compact dimensions and oil reservoir integration;
3. Tie-rod structure with pillar-connected end caps and aluminum alloy barrel ensures superior reliability;
4. Enables multi-position rod locking throughout the full stroke range;
5. Precision-adjustable pneumatic cushioning for smooth operation;
6. Configurable with multiple bore sizes and mounting accessories;
7. High-temperature resistant seals support operational range of 0-150°C.
Category: Multi-Position Force Amplifying Cylinders | Brand: AirTAC | Series: SCT80~100
AirTAC SCT80~100 Multi-Position Force Amplifying Cylinder SCT80X10X10 Technical Details
- Model Series: SCT80~100 (Specific Model: SCT80X10X10)
- Type: Multi-stage tandem cylinder with force multiplication
- Bore Size: 80mm (Standard SCT80 series)
- Stroke Configuration: 10mm × 10mm (Dual-stage compound stroke)
- Max. Output Force: 2,513N at 0.63MPa (Calculated force ratio 2.5:1)
- Operating Pressure: 0.1-1.0 MPa
- Piston Rod: Chrome-plated steel, Ø20mm
- Mounting: Standard ISO/VDMA front flange (MF1) with rear foot mounts
- Cushioning: Adjustable pneumatic cushion at both ends
- Port Size: G1/4 (NPT1/4 optional)
- Ambient Temperature: -20℃ to 80℃
- Seal Material: High-temperature NBR + PU wear rings
- Weight: 6.8kg (Dry, without accessories)
- Dimensions: 332mm(L) × 100mm(W) × 100mm(H) (Fully retracted)
- Extended Length: 332mm + 20mm (total stroke)
- Repeat Positioning Accuracy: ±0.2mm
- Max Speed: 500mm/s
- Protection Class: IP54 (Standard), IP67 optional
High-density force generator combining two piston chambers in series configuration, delivering 2.5x standard cylinder force within equivalent bore size. Features dual magnetic sensors slots (M9x1) for position feedback and hardened guide rods for anti-rotation stability. Requires filtered air (5-40μm) with lubrication (ISO VG32 recommended).
- High-torque clamping fixtures in CNC machining centers
- Press-fit assembly of automotive bearings
- Vertical lifting mechanisms for die casting extraction
- Stamping machines requiring short-stroke high-force actuation
- Robotic welding gun force control systems
Installation protocol:
Always install with 0.1-0.3mm alignment tolerance, use flexible couplings for
multi-cylinder synchronization. Lubricate through air supply (Oil Mist 1-2 drops/m³).
Allow 15mm thermal expansion gap at mounting points.
| Property | Property Value |
|---|---|
| sku | SCT80X10X10 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | <10mm> |
| Stroke | <10mm> |
