Airtac SCT80~100 Multi-Position Tandem Cylinder SCT80X10X10S
2. Features specialized bidirectional sealing profile for pistons with compact dimensions and oil reservoir integration;
3. Tie-rod structure with pillar-connected end caps and aluminum alloy barrel ensures superior reliability;
4. Enables multi-position rod locking throughout the full stroke range;
5. Precision-adjustable pneumatic cushioning for smooth operation;
6. Configurable with multiple bore sizes and mounting accessories;
7. High-temperature resistant seals support operational range of 0-150°C.
Category: Multi-Position Force Amplifying Cylinders | Brand: AirTAC | Series: SCT80~100
AirTAC SCT80X10X10S Multi-Position Intensifier Cylinder Specifications
- Model: SCT80X10X10S
- Series: SCT80~100 multi-position intensifier
- Bore size: 80 mm
- Stroke: 100 mm
- Number of intensifier stages: 2 (10-ton force output per stage)
- Max. thrust force: 20,000 N (at 0.63 MPa)
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Mounting style: Front flange (MF1) / Rear flange (MF2) optional
- Port size: G1/4 (NPT1/4 optional)
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seal type: NBR wear-resistant seals
- Repeat positioning accuracy: ±0.2 mm
- Weight: 5.8 kg (empty)
- Dimensions (L×W×H): 300×125×125 mm (basic length) + stroke-dependent extension
- Max. allowable side load: 150 N
- Lubrication: Pre-lubricated (Grease-free operation)
A high-force multi-position actuator combining pneumatic and mechanical amplification. Features dual-stage force multiplication through nested piston design, delivering 3-5× standard cylinder force. Precision ground rod and guided piston ensure stable multi-stop positioning. Includes magnetic piston for position feedback compatibility.
- Stamping/punching presses in automotive assembly
- Clamping fixtures for CNC machining centers
- Plastic injection molding ejectors
- Battery cell compression testing systems
- High-torque valve actuation in process control
Installation note:
Requires rigid mounting surface with flatness ≤0.1mm. Use locknuts with 25-30 N·m torque.
For multi-stop applications, pair with APV10 series proportional valves. Lubricate guide shafts
with ISO VG32 hydraulic oil monthly in high-cycle operations.
| Property | Property Value |
|---|---|
| sku | SCT80X10X10S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | <10mm> |
| Stroke | <10mm> |
