Airtac SCT80~100 Multi-Position Tandem Cylinder SCT80X10X150S
2. Features specialized bidirectional sealing profile for pistons with compact dimensions and oil reservoir integration;
3. Tie-rod structure with pillar-connected end caps and aluminum alloy barrel ensures superior reliability;
4. Enables multi-position rod locking throughout the full stroke range;
5. Precision-adjustable pneumatic cushioning for smooth operation;
6. Configurable with multiple bore sizes and mounting accessories;
7. High-temperature resistant seals support operational range of 0-150°C.
Category: Multi-Position Force Amplifying Cylinders | Brand: AirTAC | Series: SCT80~100
AirTAC SCT80X10X150S Multi-Position Force Amplifier Cylinder Specifications
- Model: SCT80X10X150S
- Series: SCT80~100 Force Amplifier Series
- Bore size: Ø80 mm
- Stroke: 150 mm
- Force stages: 10-stage force amplification
- Max thrust: 2,450 N (at 0.63 MPa)
- Operating pressure: 0.1–0.8 MPa
- Air consumption: 3.8 L/stroke (standard conditions)
- Cushioning: Adjustable rubber buffer + air cushion
- Body material: Aluminum alloy (anodized)
- Piston rod: Chrome-plated steel (HRC 45-50)
- Seal material: NBR/PU (temperature-resistant variant available)
- Operating temperature: -20℃ to 80℃
- Weight: 5.8 kg (excluding accessories)
- Dimensions: 320mm(L) × 130mm(W) × 130mm(H) (retracted state)
- Port size: G1/4 (standard), M5/NPT1/4 optional
- Position detection: Built-in magnet for sensor mounting
- Repeat positioning accuracy: ±0.5 mm
High-precision multi-stage force cylinder with progressive force output, featuring dual-axis stabilization and anti-rotation mechanism. The staggered piston design enables 10 distinct force levels through compressed air superposition. Requires filtered lubricated air (ISO 8573-1 class 3.4.3) and features wear-resistant guide bushings for >3,000km service life.
- Press-fit assembly of precision electronics connectors
- Variable pressure clamping in CNC fixture systems
- Progressive stamping operations in automotive parts production
- Packaging line pressure-sensitive product handling
- Battery module compression testing equipment
Installation note:
Mount using M8 mounting bolts (ISO 4762) with 22-25 N·m torque.
Maintain 0.5-1mm clearance between rod end and workpiece during alignment.
Lubricate through FRL unit with ISO VG32 turbine oil mist (1-2 drops/m³ air).
| Property | Property Value |
|---|---|
| sku | SCT80X10X150S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | <10mm> |
| Stroke | 150mm |
