Airtac UCS Polyester Helix Hose UCS060040BK030MA1
$5.80
Regulärer Preis
$13.30
Verkauf!
Einzelpreis
pro
verkauft im letzten Std.
Kunden sehen sich dieses Produkt an
Verfügbarkeit für Abholungen konnte nicht geladen werden
Artikelnummer:
Auf Lager
Artikelnummer:
UCS060040BK030MA1
Stichworte:
DELIVERY
Estimated delivery between
and
Garantiert sicherer Checkout
Beschreibung
1. Manufactured from ROHS-compliant thermoplastic polyurethane (TPU) with exceptional moldability;
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
Installation guidelines:
Use rotary cutters for clean ends, avoid sawing. When connecting to push-in fittings,
insert hose until it bottoms out then pull back 1mm. Maximum permissible lateral
vibration: 2.5mm amplitude at ≤50Hz. Not recommended for steam applications.
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
AirTAC UCS Series Polyester Coiled Hose UCS060040BK030MA1 Technical Details
- Full Model Code: UCS060040BK030MA1
- Material: Polyester elastomer (PES) with embedded steel wire reinforcement
- Inner Diameter: 4.0 mm ±0.2mm
- Outer Diameter: 6.0 mm ±0.3mm
- Standard Length: 30 meters per coil
- Color: Black (RAL 9005)
- Temperature Range: -40℃ to +120℃ (continuous use)
- Max Working Pressure: 1.2 MPa (12 bar) at 23℃
- Burst Pressure: ≥4.8 MPa
- Minimum Bend Radius: 25mm (dynamic)/15mm (static)
- Chemical Resistance: Resistant to oils, greases, and mild acids (pH 4-9)
- Certifications: RoHS compliant, REACH SVHC-free
- Weight: 0.25 kg/meter (7.5kg total per 30m coil)
- Coil Dimensions: 300mm (Diameter) × 100mm (Height)
- End Fittings Compatibility: M5, 1/8" BSPP, or custom connectors
Flexible pneumatic hose with memory-free coiling behavior, engineered for repetitive motion applications. Features anti-kink helical design with 360° rotation capability and UV stabilization for occasional outdoor use. The steel wire reinforcement prevents collapse under vacuum conditions (-0.9 bar).
Primary Applications:
- Robotic arm tool changers in automotive assembly lines
- CNC machine tool coolant line management
- Pharmaceutical blister packaging equipment
- Semiconductor wafer handling vacuum systems
- Mobile agricultural machinery control circuits
Installation guidelines:
Use rotary cutters for clean ends, avoid sawing. When connecting to push-in fittings,
insert hose until it bottoms out then pull back 1mm. Maximum permissible lateral
vibration: 2.5mm amplitude at ≤50Hz. Not recommended for steam applications.
Pressure-Temperature Relationship:
- 1.2 MPa @ 23℃ → 0.9 MPa @ 80℃ → 0.6 MPa @ 120℃
- Vacuum rating maintained up to 80℃ ambient temperature
| Property | Property Value |
|---|---|
| sku | UCS060040BK030MA1 |
| Inner Diameter | 4.0mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | <38mm> |
| Material Length | 3M |
| Color | Black |
