Airtac UCS Polyester Helix Hose UCS060040BK030MB2
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
AirTAC UCS Polyester Coiled Hose UCS060040BK030MB2 Specifications
- Model Code: UCS060040BK030MB2
- Material: Polyester (PUR) with embedded steel wire reinforcement
- Inner Diameter: 6.0 mm ±0.3mm
- Outer Diameter: 10.0 mm ±0.5mm
- Standard Length: 3 meters (customizable up to 15m)
- Color: Black (BK)
- Temperature Range: -20℃ to +80℃
- Bending Radius: ≥24mm (4×ID)
- Working Pressure: 0.3-1.0 MPa (4.35-145 psi)
- Burst Pressure: ≥3.0 MPa
- Weight: 0.15kg/m ±5% (0.45kg total for 3m)
- Connector Type: MB2 series stainless steel quick plugs
- Anti-static: ≤10^6 Ω (ISO 8031 compliant)
- Certification: RoHS/REACH compliant
Helically wound polyurethane tubing with superior kink resistance and memory retention. Features UV/Ozone resistance and low gas permeability, maintaining 95% pressure retention after 5000 flex cycles. The MB2 connectors enable tool-free installation with 180° swivel capability.
- Robotic arm pneumatic tooling (EOAT)
- CNC machine coolant line management
- Semiconductor fab equipment air supply
- Automated packaging line actuator connections
- Food processing vacuum gripping systems
Installation protocol:
Always maintain minimum bend radius during routing. Use spiral wraps
in high-vibration environments. For vacuum applications, pre-stretch
hose by 5-7% before final connection. Replace if surface cracks exceed
0.2mm depth.
| Property | Property Value |
|---|---|
| sku | UCS060040BK030MB2 |
| Inner Diameter | 4.0mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | <38mm> |
| Material Length | 3M |
| Color | Black |
