Airtac UCS Polyester Helix Hose UCS060040BK060MA3
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
AirTAC UCS Polyester Coiled Hose UCS060040BK060MA3 Technical Details
- Full Model Code: UCS060040BK060MA3
- Material: High-flex polyester with PVC coating
- Inner Diameter: 6.0 mm (±0.3mm tolerance)
- Outer Diameter: 9.5 mm (±0.5mm tolerance)
- Coiled Length: 4000 mm (4 meters extended)
- Natural Retracted Length: 600 mm
- Color Code: BK (Black UV-resistant finish)
- Temperature Range: -20℃ to +80℃ (continuous use)
- Max Pressure: 1.0 MPa (10 bar)
- Burst Pressure: ≥3.0 MPa
- Weight: 280g/m (extended) / 980g total coiled unit
- Dimensions (Coiled): Ø60mm × H60mm
- End Fittings: M3 male threaded connectors (brass)
- Certification: RoHS compliant, REACH tested
- Minimum Bend Radius: 30mm (dynamic applications)
High-performance spiral reinforcement hose with 360° flexible memory structure, engineered for repetitive motion systems. Features anti-kink design and abrasion-resistant outer layer with 2mm wall thickness. Compatible with air, water, and mild chemicals (pH 3-11). Includes integrated strain relief at connectors.
- Robotic arm pneumatic tooling
- CNC machine coolant lines
- 3D printer filament guides
- Medical device cable management
- Automated packaging line actuators
Installation guidelines:
Maintain 1.5×OD clearance from heat sources. For optimal performance,
pre-stretch coiled hose to 80% of max length before fixing endpoints.
Use spiral rotation direction matching machine motion path (clockwise/CCW).
| Property | Property Value |
|---|---|
| sku | UCS060040BK060MA3 |
| Inner Diameter | 4.0mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | <38mm> |
| Material Length | M6 |
| Color | Black |
