Airtac UCS Polyester Helix Hose UCS060040BK060MB1
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
AirTAC UCS Polyester Spiral Tube UCS060040BK060MB1 Technical Details
- Full Model: UCS060040BK060MB1
- Series: UCS Heavy-Duty Spiral Tube
- Material: Reinforced polyester (PUR) with abrasion-resistant coating
- Inner Diameter: 6.0 mm ±0.3mm
- Outer Diameter: 10.5 mm ±0.5mm
- Standard Length: 6 meters (customizable up to 30m)
- Bend Radius: 40mm minimum (cold state)
- Temperature Range: -40℃ to +120℃ (instantaneous peak 150℃)
- Pressure Rating: 0.3-1.2 MPa (4-17 psi)
- Color Code: BK = Black (UV-resistant formulation)
- Weight: 92g/m ±5% (Approx 552g for 6m unit)
- Coiling Dimensions: 400mm(D) × 400mm(W) × 250mm(H) when fully coiled
- Certifications: RoHS compliant, REACH SVHC-free
- Anti-static Option: Surface resistance <10^9 Ω (optional)
High-flex spiral protection hose with memory retention, engineered for continuous motion applications. Features 360° torsion stability and anti-kink reinforcement ribs. The corrugated design enables 25% stretch capability while maintaining pressure integrity. Compatible with ISO 1436-1A standard fittings.
- Robotic arm pneumatic tooling (7th axis applications)
- CNC machine automatic tool changers
- Food processing vacuum systems (FDA-compliant material version)
- Plastic injection molding machine ejectors
- Semiconductor wafer handling equipment
Installation Tip:
For optimal performance in high-cycle applications, pre-stretch the tube to 110% of installed length
before clamping. Avoid sharp edge contact using protective sleeves at mounting points.
| Property | Property Value |
|---|---|
| sku | UCS060040BK060MB1 |
| Inner Diameter | 4.0mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | <38mm> |
| Material Length | M6 |
| Color | Black |
