Airtac UCS Polyester Helix Hose UCS060040BK060MB3
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
AirTAC UCS Polyester Spiral Tube UCS060040BK060MB3 Technical Details
- Full Model Code: UCS060040BK060MB3
- Material: High-grade oil-resistant polyester (PES) with embedded steel wire reinforcement
- Inner Diameter: 6.0 mm ±0.3mm
- Outer Diameter: 10.5 mm (nominal)
- Standard Length: 6 meters per coil
- Color: Black (BK) with wear-indication stripes
- Temperature Range: -20℃ to +80℃ continuous operation
- Max Working Pressure: 1.0 MPa (10 bar)
- Burst Pressure: ≥3.0 MPa
- Weight: 0.28 kg/m → 1.68 kg per 6m coil
- Coil Dimensions: 400mm(W) × 400mm(H) × 300mm(D) packed in anti-UV PE bag
- Bend Radius: 40mm minimum
- Flame Rating: UL94 V-2 compliant
- Chemical Resistance: Resists hydraulic oils (ISO VG32-68), weak acids, and alkalis
Multi-layer spiral protection tube featuring a smooth inner surface for reduced pneumatic friction loss (pressure drop <0.02MPa at 0.5MPa input). The steel wire helix provides crush resistance up to 750N/5cm while maintaining 360° flexibility. Includes UV stabilizers for outdoor durability.
- CNC machine tool pneumatic line protection
- Robotic arm cable management in automotive assembly
- Packaging machinery air supply circuits
- Semiconductor fab equipment (cleanroom compatible)
- Hydraulic sensor line shielding
Installation protocol:
Cut with rotary pipe cutter only. Always maintain 15% length slack during routing.
For high-vibration environments, use every 50cm with ADT-6CL clamps (sold separately).
| Property | Property Value |
|---|---|
| sku | UCS060040BK060MB3 |
| Inner Diameter | 4.0mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | <38mm> |
| Material Length | M6 |
| Color | Black |
