Airtac UCS Polyester Helix Hose UCS060040BK060MC3
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
AirTAC UCS Polyester Coiled Hose UCS060040BK060MC3 Technical Details
- Full Model Code: UCS060040BK060MC3
- Material: Polyester outer layer + PVC inner tube
- Inner Diameter: 6.0 mm (±0.3mm tolerance)
- Outer Diameter: 10.0 mm (±0.5mm tolerance)
- Standard Length: 6 meters (customizable up to 50m)
- Color: Black (BK) with yellow tracer line
- Temperature Range: -20℃ to +80℃
- Max Working Pressure: 1.0 MPa (10 bar)
- Burst Pressure: ≥3.0 MPa
- Weight: 60g/m (±5%) → 360g total for 6m
- Coiled Diameter: 140mm (natural state)
- Straightened Length Tolerance: +2%/-0%
- Certification: RoHS compliant
Multi-layer reinforced spiral hose featuring exceptional kink resistance and memory retention. The corrugated design enables 30% greater bend radius flexibility compared to standard PU tubes. Oil-resistant PVC inner layer prevents plasticizer migration, while the polyester braiding provides 360° abrasion protection. Includes UV stabilization for outdoor use.
- Pneumatic tool connections in automotive assembly lines
- Robotic arm end-effector air supply (6-axis applications)
- Packaging machinery with reciprocating motion requirements
- Mobile equipment requiring coil memory (e.g., CNC tool changers)
- Laboratory automation with frequent position adjustments
Maintenance Tip:
When routing through cable carriers, maintain minimum bend radius of 80mm.
For dust-prone environments, use protective sleeve SA-6. Compatible with
push-to-connect fittings up to PT1/4 size. Avoid exposure to ester-based
lubricants.
| Property | Property Value |
|---|---|
| sku | UCS060040BK060MC3 |
| Inner Diameter | 4.0mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | <38mm> |
| Material Length | M6 |
| Color | Black |
