Airtac UCS Polyester Helix Hose UCS060040BK090MA1
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
AirTAC UCS Polyester Spiral Hose UCS060040BK090MA1 Technical Details
- Model Code: UCS060040BK090MA1
- Material: Oil-resistant polyester (PES) with steel wire reinforcement
- Inner Diameter: 4.0 mm ±0.2mm
- Outer Diameter: 6.0 mm ±0.3mm
- Standard Length: 9 meters (customizable)
- Color: Black (BK) with yellow spiral stripe
- Temperature Range: -20℃ to +80℃ (continuous use)
- Max Pressure: 1.0 MPa (10 bar) at 23℃
- Bend Radius: 25mm minimum (cold state)
- End Fittings: M5 x 0.8 straight threaded connectors (brass)
- Weight: ~250g/m (total ~2.25kg for 9m coil)
- Coil Dimensions: 400mm(D) × 400mm(W) × 120mm(H) (compressed shipping package)
- Certification: RoHS compliant, ISO 14001 manufacturing
High-flex spiral protection hose with anti-kink design, featuring 3-layer construction: inner smooth bore for low flow resistance, middle steel helix for crush resistance, and outer abrasion-resistant textile braid. Specialized for dynamic pneumatic applications requiring tight bend capability.
- Robotic arm pneumatic tooling circuits
- CNC machine coolant line protection
- Automated packaging line air blow systems
- Semiconductor equipment vacuum lines
- Food processing machinery (compatible with FDA-grade air)
Installation guidance:
Maintain 10% extra length allowance during routing to prevent tension.
Use spiral rotation direction (right-hand helix) for natural coil alignment.
Avoid sharp edges within 150mm of connection points.
| Property | Property Value |
|---|---|
| sku | UCS060040BK090MA1 |
| Inner Diameter | 4.0mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | <38mm> |
| Material Length | 9M |
| Color | Black |
