Airtac UCS Polyester Helix Hose UCS060040BK090MA3
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
AirTAC UCS Polyester Spiral Hose UCS060040BK090MA3 Technical Details
- Full Model Code: UCS060040BK090MA3
- Series: UCS (Ultra-flexible Corrosion-resistant Spiral)
- Inner Diameter: 6.0 mm ±0.3mm
- Outer Diameter: 10.0 mm (with spiral reinforcement)
- Length: 9 meters (9000mm) coiled
- Material: Polyester + PVC inner layer
- Color: BK (Black with yellow tracer line)
- Bend Radius: 24mm (4×ID minimum)
- Temperature Range: -40℃ to +120℃ (-40℉ to 248℉)
- Working Pressure: 1.0 MPa (145 psi) max @ 23℃
- Burst Pressure: ≥3.0 MPa (435 psi)
- Weight: 0.15 kg/m (1.35kg total coiled weight)
- Coil Dimensions: 300mm (D) × 150mm (H)
- Certification: REACH/ROHS compliant
- Surface Resistance: 10^3-10^6 Ω (anti-static version available)
Multi-layer spiral hose with embedded reinforcement wire, engineered for high-flex pneumatic applications. Features UV resistance (ISO4892-2 tested) and chemical resistance to oils/weak acids. The smooth inner bore minimizes pressure drop, while the abrasion-resistant outer layer withstands 50,000+ flex cycles (ISO6802 test standard).
- Robotic end-effector tooling (ISO 9409-1 compatible)
- Plastic injection molding machine umbilicals
- Food-grade pneumatic systems (FDA-compliant material option)
- Semiconductor wafer handling equipment
- High-cycle packaging line actuators
Installation Guidelines:1. Maintain minimum 2×ID bend radius during routing
2. Use PPS (Push-in Pneumatic Socket) connectors with 6mm tube OD
3. Avoid continuous exposure to temperatures >80℃ near joints
4. Replace if outer spiral shows >30% wire deformation
- 0.3 MPa: 0.002 bar/m loss @ 20℃
- 0.6 MPa: 0.005 bar/m loss @ 20℃
- 1.0 MPa: 0.012 bar/m loss @ 20℃
| Property | Property Value |
|---|---|
| sku | UCS060040BK090MA3 |
| Inner Diameter | 4.0mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | <38mm> |
| Material Length | 9M |
| Color | Black |
