Airtac UCS Polyester Helix Hose UCS060040BK090MB1
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
AirTAC UCS Polyester Coiled Hose UCS060040BK090MB1 Technical Details
- Full Model Code: UCS060040BK090MB1
- Series: UCS Standard Duty Coiled Hose
- Material: Thermoplastic polyester elastomer (TPEE)
- Inner Diameter: 6.0 mm ±0.3mm
- Outer Diameter: 10.0 mm ±0.5mm
- Coil Length: 900mm (Extended length: ~3 meters)
- Color: Black (BK)
- Burst Pressure: ≥1.2 MPa
- Operating Temperature: -10°C to +70°C
- Weight: 0.35kg/m (Total ~1.05kg for 3m extended length)
- Coiled Dimensions: Ø300mm × 120mm (Diameter × Height)
- Certification: RoHS compliant
- Tube Hardness: 90±5 Shore A
- Minimum Bend Radius: 30mm
Flexible pneumatic hose with memory-retention coil design for automated equipment requiring extended reach with spring-back capability. Features oil-resistant TPEE construction with smooth inner bore (Ra≤0.8μm) for optimal airflow. Anti-kink reinforcement prevents collapse during vacuum applications.
- Robotic arm end effectors in assembly lines
- Mobile pneumatic tools with dynamic movement
- CNC machine tool coolant control systems
- Packaging machinery with reciprocating actuators
- Laboratory automation fluid handling
Installation guidance:
Maintain 50% stretch margin during installation. Avoid sharp edges near connection points -
use protective sleeves when routing through metal panels. Pre-stretch coils before
initial use to eliminate memory tension. Maximum continuous working pressure: 0.8MPa.
| Property | Property Value |
|---|---|
| sku | UCS060040BK090MB1 |
| Inner Diameter | 4.0mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | <38mm> |
| Material Length | 9M |
| Color | Black |
