Airtac UCS Polyester Helix Hose UCS060040BK090MB3
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
AirTAC UCS Polyester Spiral Tube UCS060040BK090MB3 Specifications
- Model: UCS060040BK090MB3
- Material: High-grade polyester (PET) with anti-static additives
- Inner diameter: 6.0 mm ±0.3mm
- Outer diameter: 10.0 mm ±0.5mm
- Standard length: 900 mm (35.4")
- Weight: 0.15 kg/m (0.33 lb/ft)
- Coiled dimensions: Ø150mm × W90mm (compressed state)
- Temperature range: -40℃ to 120℃ continuous use
- Pressure resistance: ≤1.0 MPa (145 psi)
- Elongation rate: ≥300% (before plastic deformation)
- Color: Black (BK) with matte finish
- Certification: RoHS compliant, UL 94 V-2 flame rated
- Minimum bending radius: 25mm (dynamic) / 15mm (static)
Multi-layer reinforced spiral tubing with memory retention, designed for demanding pneumatic and cable protection applications. Features UV resistance and anti-abrasion coating (MB3 grade), maintaining flexibility across extreme temperature variations. The interlocking spiral design prevents kinking while allowing axial stretch compensation.
- Robotic arm cable management in automotive assembly lines
- CNC machine tool pneumatic sensor line protection
- Food processing equipment (FDA-compliant material version)
- Outdoor industrial vacuum systems with particle abrasion
- High-cycle packaging machine air cylinder connections
Installation note:
Cut with rotary tube cutter for clean edges. When routing cables, maintain 70% fill ratio maximum.
For thermal expansion compensation, allow 5% extra length per 20℃ temperature increase.
| Property | Property Value |
|---|---|
| sku | UCS060040BK090MB3 |
| Inner Diameter | 4.0mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | <38mm> |
| Material Length | 9M |
| Color | Black |
