Airtac UCS Polyester Helix Hose UCS060040BK120MA2
$18.11
Regulärer Preis
$25.61
Verkauf!
Einzelpreis
pro
verkauft im letzten Std.
Kunden sehen sich dieses Produkt an
Verfügbarkeit für Abholungen konnte nicht geladen werden
Artikelnummer:
Auf Lager
Artikelnummer:
UCS060040BK120MA2
Stichworte:
DELIVERY
Estimated delivery between
and
Garantiert sicherer Checkout
Beschreibung
1. Manufactured from ROHS-compliant thermoplastic polyurethane (TPU) with exceptional moldability;
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
Installation Guidelines:
1. Pre-stretch 10% before fixing endpoints to prevent buckling
2. Maintain 1.5×OD clearance from adjacent surfaces
3. Use spiral-compatible P-clips every 300mm
4. Avoid sharp edges – install wear sleeves at penetration points
2. High elasticity: Compact bend radius enables tight routing in confined spaces;
3. Kink-resistant design: Superior anti-kinking performance versus standard plastic tubing;
4. Outstanding shape memory: Endures repeated extension/retraction cycles without deformation;
5. Abrasion-resistant construction: Extended service life in high-wear industrial environments;
6. Low gas permeability: Minimizes leakage risks and fluid contamination;
7. Excellent solvent resistance: Eliminates environmental contamination from material degradation;
8. Minimal compression deformation: Maintains structural integrity under pressure;
9. Media compatibility: Suitable for compressed air and water systems.
Category: Spring Tube | Brand: AirTAC | Series: UCS Series
AirTAC UCS Polyester Spiral Hose UCS060040BK120MA2 Technical Details
- Model Code Breakdown:
- UCS: Universal Coil Spiral series
- 06: 6mm inner diameter
- 0040: 40 meters per coil
- BK: Black color
- 120: 12mm pitch (spiral interval)
- MA2: Material version (Polyester reinforced)
- Inner Diameter: 6.0 ±0.3mm
- Outer Diameter: 8.5 ±0.4mm
- Bending Radius: ≥35mm (dynamic) / ≥25mm (static)
- Temperature Range: -20℃ to +120℃ (instantaneous peak 150℃)
- Pressure Rating: 0.8MPa max (8 bar)
- Tensile Strength: ≥120N
- Elongation at Break: ≤15%
- Twist Resistance: ≤3° per meter under 5Nm torque
- Material Composition:
- Core: Polyester monofilament reinforcement
- Jacket: Thermoplastic polyester elastomer (TPEE)
- UV Stabilizer: Carbon black (3% content)
- Weight: 0.65kg/meter (linear) | 26kg per 40m coil
- Coil Dimensions: 320mm (W) × 320mm (D) × 220mm (H)
- Certifications: RoHS 2.0, REACH SVHC, ISO 14001
- Flame Rating: UL94 V-2 compliant
High-flex spiral hose with memory retention, engineered for continuous motion applications. Features three-layer construction: inner abrasion-resistant TPEE, middle spiral reinforcement, and outer anti-static coating. Maintains shape integrity through >1 million flex cycles at 0.5Hz. Includes UV protection for outdoor use up to 2,000hrs sunlight exposure.
Industrial Applications:
- Robotic arm cable management (6-axis articulation points)
- CNC machine tool coolant hose protection
- Automated warehouse stacker crane energy chains
- Food-grade environments (FDA-compliant material)
- 3D printer filament guides with low particulate generation
Installation Guidelines:1. Pre-stretch 10% before fixing endpoints to prevent buckling
2. Maintain 1.5×OD clearance from adjacent surfaces
3. Use spiral-compatible P-clips every 300mm
4. Avoid sharp edges – install wear sleeves at penetration points
Chemical Resistance:
- Excellent resistance to: Hydraulic oils (ISO VG 32-68), cutting fluids, 10% NaOH solution
- Limited resistance to: Ketones, concentrated acids (>30%)
- Not compatible with: Chlorinated solvents, aromatic hydrocarbons
| Property | Property Value |
|---|---|
| sku | UCS060040BK120MA2 |
| Inner Diameter | 4.0mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | <38mm> |
| Material Length | 12M |
| Color | Black |
