Airtac 100M Solenoid Valve Manifold 100M-17F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Features centralized air supply ports and unified wiring channels, significantly enhancing system maintainability and simplified troubleshooting;
3、Provides modular flexibility with scalable configuration options, supporting adaptable expansion of connected directional control valves as required;
Category: Solenoid Valve Base , Brand: AIRTAC , Series: 100M
AirTAC 100M-17F Solenoid Valve Base Specifications
- Model: 100M-17F (Multi-port manifold base)
- Compatible valve series: 100A/100B/100C solenoid valves
- Port configuration: 5/2-way or 5/3-way valve mounting (modular design)
- Port thread size: G1/8, G1/4, or NPT1/4 (customizable)
- Max operating pressure: 1.0 MPa
- Material: Glass fiber reinforced nylon (PA66+GF25%)
- Installation spacing: 18mm between valve positions
- Weight: 235g ±5% (bare base without valves)
- Dimensions: 80mm(L) × 25mm(W) × 41mm(H)
- Temperature resistance: -5℃ to 60℃ (with NBR seals)
- Pressure drop: ≤0.02 MPa at 750 L/min flow rate
- Mounting: DIN rail compatible (TS35) or direct screw mounting
Modular manifold base engineered for multi-valve pneumatic systems, featuring zero-leakage stacked design with integrated air passages. The staggered port arrangement reduces hose entanglement, while the anti-vibration structure maintains stable connections during operation. Compatible with ISO 5599-1 mounting patterns.
- Multi-cylinder sequencing in automated assembly lines
- Centralized control of pneumatic actuators in CNC machinery
- Textile manufacturing equipment air circuit distribution
- Beverage filling systems with multi-station control
- Semiconductor handling robots
Installation note:
Apply 3-5Nm torque during valve mounting. Use Loctite 542 on thread joints
for high-vibration environments. Maximum recommended stack height: 10 units.
- Use with 100A-12 valve for general industrial applications
- Combine with 100B-15 valves for vacuum systems
- Pair with 100C-18 valves for low-power consumption setups
| Property | Property Value |
|---|---|
| sku | 100M-17F |
