Airtac 100M Solenoid Valve Manifold 100M-2F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Features centralized air supply ports and unified wiring channels, significantly enhancing system maintainability and simplified troubleshooting;
3、Provides modular flexibility with scalable configuration options, supporting adaptable expansion of connected directional control valves as required;
Category: Solenoid Valve Base , Brand: AIRTAC , Series: 100M
AirTAC 100M-2F Solenoid Valve Base Specifications
- Model: 100M-2F
- Type: ISO 5599/1 Standard Manifold Base (2-position)
- Port size: G1/8 (ISO 228-1 standard)
- Max operating pressure: 1.0 MPa
- Mounting compatibility: 100M series solenoid valves
- Weight: ~220g (bare base)
- Dimensions: 62mm(L) × 24mm(W) × 32mm(H)
- Material: Glass fiber reinforced PA66
- Seal type: Integral O-ring groove design
- Temperature resistance: -20℃ to 80℃
- Port thread depth: 10mm (minimum engagement)
- Flow capacity: 750 Nl/min (at 0.5MPa)
- Surface finish: Ra 3.2μm (mounting surface)
Modular manifold base enabling multi-valve stacking with precision alignment pins. Features integrated pressure retention grooves and cross-port bleed channels. Compatible with 100M-3F/4F series for system expansion. Anodized aluminum mounting hardware included.
- Centralized control systems for plastic injection molding machines
- Multi-station pneumatic test benches
- Automated assembly line actuator clusters
- CNC machine tool clamping circuits
- Robotic end-effector pneumatic networks
Installation protocol:
Apply 2-3Nm torque during manifold stacking. Use Loctite 243 threadlocker
on mounting screws. Maintain 0.02mm flatness tolerance on mounting surface.
- Pressure drop: ≤0.05MPa at max flow
- Leakage rate: <5 cm³/min (bubble test at 0.6MPa)
- Response time: 15ms (pressure build-up from 0-0.63MPa)
| Property | Property Value |
|---|---|
| sku | 100M-2F |
