Airtac 100M Solenoid Valve Manifold 100M-3F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Features centralized air supply ports and unified wiring channels, significantly enhancing system maintainability and simplified troubleshooting;
3、Provides modular flexibility with scalable configuration options, supporting adaptable expansion of connected directional control valves as required;
Category: Solenoid Valve Base , Brand: AIRTAC , Series: 100M
AirTAC 100M-3F Solenoid Valve Base Specifications
- Model: 100M-3F
- Type: 3/2-way manifold base for pilot-operated valves
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage compatibility: DC24V ±10%, AC110V ±10%(50/60Hz), AC220V ±10%(50/60Hz)
- Weight: 280g ±5% (excluding connected components)
- Dimensions: 58mm(L) × 42mm(W) × 35mm(H)
- Seal material: FKM fluorocarbon rubber (Viton® equivalent)
- Temperature tolerance: -10℃ to 80℃ (14°F to 176°F)
- Power consumption: ≤2.5W (at DC24V)
- Protection class: IP67 (dust-tight and protected against temporary immersion)
- Compatible valve bodies: All 100M series solenoid valves
- Mounting pattern: Baseplate with M5 threaded holes (16mm pitch)
High-flow manifold base engineered for modular pneumatic systems, featuring chemical-resistant FKM seals for aggressive environments. The anodized aluminum construction ensures EMI shielding and heat dissipation. Designed with dual-row terminal blocks for daisy-chaining multiple valves. Requires 5μm filtered/dried air with ISO 8573-1:2010 Class 3 purity standards.
- Multi-station pneumatic control panels
- Plastic injection molding machines
- Food processing equipment (NSF-compliant version available)
- Automated assembly line actuators
- Semiconductor manufacturing tools
Installation guidelines:
Torque mounting screws to 0.6-0.8N·m using cross-tightening sequence.
Maintain 20mm clearance below base for wiring maintenance.
Lubricate O-rings with silicone grease (Parker Super O-Lube recommended) during assembly.
| Property | Property Value |
|---|---|
| sku | 100M-3F |
