Airtac 100M Solenoid Valve Manifold 100M-5F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Features centralized air supply ports and unified wiring channels, significantly enhancing system maintainability and simplified troubleshooting;
3、Provides modular flexibility with scalable configuration options, supporting adaptable expansion of connected directional control valves as required;
Category: Solenoid Valve Base , Brand: AIRTAC , Series: 100M
AirTAC 100M-5F Valve Manifold Base Technical Details
- Model designation: 100M-5F
- Base type: 5-station modular manifold
- Material: Glass fiber reinforced nylon (PA66+GF25%)
- Port thread size: PT1/8 (NPT1/8 optional)
- Max operating pressure: 0.9 MPa
- Min operating pressure: 0.1 MPa
- Temperature tolerance: -5℃ to 60℃
- Port configuration: 5 independent circuits
- Compatible valves: 100 series solenoid valves
- Seal type: Integrated O-ring groove design
- Weight: 220g ±5%
- Dimensions: 78mm(L) × 40mm(W) × 25mm(H)
- Surface finish: Anti-corrosion anodizing
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Multi-channel distribution block engineered for centralized pneumatic control systems. Features unified air supply design with 5 isolated flow paths, enabling simultaneous operation of multiple actuators. The staggered port arrangement prevents tool interference during manifold assembly. Compatible with ISO 15407-1 standard valve bodies.
- Modular pneumatic control panels in automotive assembly lines
- Multi-axis robotic gripper synchronization systems
- Plastic injection molding machine air circuits
- Beverage filling station valve clusters
- Semiconductor wafer handling equipment
Installation protocol:
Use M4×12 stainless steel mounting screws (2.5N·m torque limit).
Apply silicone-free thread sealant on ports 2-5. Allow 15mm clearance
above base for valve maintenance. Perform air tightness test at 0.6MPa
for 3 minutes post-installation.
| Property | Property Value |
|---|---|
| sku | 100M-5F |
