Airtac 100M Solenoid Valve Manifold 100M-7F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Features centralized air supply ports and unified wiring channels, significantly enhancing system maintainability and simplified troubleshooting;
3、Provides modular flexibility with scalable configuration options, supporting adaptable expansion of connected directional control valves as required;
Category: Solenoid Valve Base , Brand: AIRTAC , Series: 100M
AirTAC 100M-7F Manifold Base Technical Details
- Model: 100M-7F
- Type: Modular solenoid valve manifold base
- Port configuration: 7 stations (supports multiple valve stacking)
- Port size: PT1/4 (G1/8 optional)
- Max operating pressure: 1.0 MPa
- Temperature resistance: -5℃ to 60℃ (with NBR seals)
- Material: Reinforced PA66 + 30% glass fiber
- Surface finish: Oxidation-resistant treatment
- Weight: 385g ±5g
- Dimensions: 156mm(L) × 19.5mm(W) × 42mm(H)
- Port pitch: 18mm (center-to-center spacing)
- Compatibility: Matches 100M series valves and SY series solenoids
- Flow characteristics: Cv=1.2 (at 7 bar)
- Thread depth: 12mm (for secure fitting engagement)
Multi-channel manifold base engineered for centralized pneumatic circuit management. Features integrated air passages with leak-proof design, enabling simultaneous control of multiple actuators. The anodized aluminum alloy end plates enhance structural rigidity, while standardized mounting slots (ISO 15407-1 compliant) ensure seamless integration with industrial automation systems.
- Automated production line multi-cylinder synchronization systems
- PLC-controlled pneumatic assembly stations
- Textile machinery air circuit distribution hubs
- Semiconductor handling equipment cluster control
- Multi-axis robotic end effector supply units
Installation protocol:
Clean air passages with dry nitrogen before assembly. Use torque-controlled wrench
(1.5-2.0 N·m) for valve mounting to prevent material stress. Maintain 0.5mm minimum
clearance between stacked units for thermal expansion.
| Property | Property Value |
|---|---|
| sku | 100M-7F |
