Airtac 100M Solenoid Valve Manifold 100M-8F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Features centralized air supply ports and unified wiring channels, significantly enhancing system maintainability and simplified troubleshooting;
3、Provides modular flexibility with scalable configuration options, supporting adaptable expansion of connected directional control valves as required;
Category: Solenoid Valve Base , Brand: AIRTAC , Series: 100M
AirTAC 100M-8F Solenoid Valve Base Specifications
- Model: 100M-8F
- Type: Modular valve manifold base
- Compatible Valves: 100M series solenoid valves
- Port Configuration: 8 positions (4 inlet/4 outlet)
- Port Size: PT1/8 (G1/8 optional)
- Material: Aluminum alloy (anodized surface treatment)
- Operating Pressure: 0.1–1.0 MPa
- Temperature Range: -5℃ to 80℃
- Seal Material: NBR/HNBR/FKM (standard NBR)
- Mounting: DIN rail TS35 or screw fixation
- Weight: 350g ±5%
- Dimensions: 90mm(L) × 30mm(W) × 55mm(H)
- Port Pitch: 18mm center-to-center
- Surface Hardness: HV 80-100
- Air Leakage: ≤30 mL/min (at 0.5 MPa)
Multi-station manifold base designed for centralized control of pneumatic circuits, featuring integrated flow paths and standardized port alignment. The staggered O-ring groove design ensures leak-proof connections even under vibration conditions. Compatible with ISO 15407-1 standards for modular valve systems.
- Multi-cylinder synchronization systems
- Automated assembly line manifolds
- Packaging machinery cluster control
- Robotic end-effector pneumatic distribution
- Semiconductor manufacturing equipment
Installation note:
Use torque-controlled wrench (0.7-1.2 N·m) for valve mounting.
Apply silicone-free lubricant to O-rings and verify manifold flatness
(≤0.1mm variance) before assembly. Maintain ambient humidity below 90% RH.
- Expandable up to 16 stations with coupling kits
- Optional exhaust silencers (AS-01 series)
- Field-replaceable manifold seals (RK-100M kit)
- Custom port labeling available (laser engraving)
| Property | Property Value |
|---|---|
| sku | 100M-8F |
