Airtac 100M Solenoid Valve Manifold 100M-9F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Features centralized air supply ports and unified wiring channels, significantly enhancing system maintainability and simplified troubleshooting;
3、Provides modular flexibility with scalable configuration options, supporting adaptable expansion of connected directional control valves as required;
Category: Solenoid Valve Base , Brand: AIRTAC , Series: 100M
AirTAC 100M-9F Manifold Base Technical Specifications
- Model: 100M-9F
- Type: Modular solenoid valve manifold base
- Material: Aerospace-grade aluminum alloy (anodized surface)
- Port configuration: 9 stations (expandable via side connectors)
- Port thread size: G1/8 (ISO228 standard)
- Max operating pressure: 1.0 MPa
- Temperature resistance: -10℃ to 80℃
- Surface hardness: HV1200±50
- Weight: 180g ±5%
- Dimensions: 52mm(W) × 35mm(H) × 18mm(D) per station
- Seal type: Dual-layer NBR/Silicone compound gasket
- Mounting pattern: ISO 15407-1 compliant
- Vibration resistance: 10-55Hz with 1.5mm amplitude
Precision-machined manifold base with integrated air passages for multi-valve systems. Features self-aligning sealing surfaces and anti-corrosion treatment, designed for high-density valve arrangements in compact installations. Compatible with 100M series valves and optional pressure sensors.
- Multi-axis pneumatic actuator control in assembly robots
- Centralized air distribution for packaging line diverters
- Modular vacuum cup arrays in material handling systems
- PLC-controlled pneumatic test benches
- Multi-station leak detection equipment
Installation protocol:
Apply 3-5Nm torque during mounting. Use PTFE tape on NPT threads.
For vertical stacks exceeding 5 units, install intermediate support brackets.
| Property | Property Value |
|---|---|
| sku | 100M-9F |
