Airtac 200M Solenoid Valve Base 200M-1F
Genuine AirTAC valve manifold, order code 200M-1F from the 4AM range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Manifold200M (for 4A200)
- Stations1 station
- ThreadPT
- Models100M / 200M / 300M / 400M
- For valves4A100 / 4A200 / 4A300 / 4A400
- Maximum stations16 / 16 / 12 / 8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 200M Solenoid Valve Base 200M-1F
A single 4A200 valve is all the 200M-1F carries: it is the one-station entry into the 200M manifold range, giving the valve a dedicated base with a 1/4 inch supply port P and PT threads, since the thread field in the order code is left blank. Ordering the manifold version keeps mounting, sealing and the screw set consistent with larger 200M banks.
The body is only 44 mm long, the shortest length in the family, because length A equals 44 mm for one station and grows by 23 mm with every further station. AirTAC supplies the manifold with seals and screws; the fluid must be air filtered to 40 um and the working temperature range is -20 to +70 C.
Airtac 200M Solenoid Valve Base 200M-1F Technical Specifications
| Order code | 200M-1F |
|---|---|
| Product | Valve Manifold |
| Manifold | 200M (for 4A200) |
| Stations | 1 station |
| Thread | PT |
| Models | 100M / 200M / 300M / 400M |
|---|---|
| For valves | 4A100 / 4A200 / 4A300 / 4A400 |
| Maximum stations | 16 / 16 / 12 / 8 |
| Supply port P | 1/4" / 1/4" / 3/8" / 1/2" |
| Length A | 100M 38 + 19 × (n-1) mm; 200M 44 + 23 × (n-1) mm; 300M 52 + 28 × (n-1) mm; 400M 61 + 35 × (n-1) mm |
| Fluid | Air, filtered to 40 µm |
| Temperature | -20 to +70 °C |
| Included | Manifold, seals and screws |
| Blank plate | Kit P-□00M-R2 (separate) |
Source: AirTAC 4A manifold datasheet (p.124), ordering code, specifications and dimensions.
How to choose
Pick 200M-1F for a lone 4A200 valve; the 200M-2F doubles the capacity on a 67 mm body, and codes up to 200M-16F reach the sixteen-station maximum. If your valve is a 4A100, 4A300 or 4A400, the matching single-station bases are 100M-1F, 300M-1F or 400M-1F instead. For G or NPT threads, order the G or T code ending rather than this blank-thread PT version.
Applications
Single-station test rigs
Mount one 4A200 valve on a 44 mm base with its own 1/4 inch supply port when a bench or test rig needs just one air-piloted valve.
Pilot signal panels
Use the single station where one valve feeds a larger actuator and the manifold base keeps the valve sealed and aligned without loose piping.
Compact machine add-ons
Add one 4A200 function to an existing machine using a supplied seal and screw set instead of bracketing a standalone valve.
FAQ
What is included and what threads does the 200M-1F use?
The order covers the manifold with seals and screws for one 4A200 valve. Threads are PT because the code has a blank thread field; G or NPT need the G or T ending.
What are the key figures of this code in one place?
One station, length A 44 mm, supply port P 1/4 inch, fluid air filtered to 40 um, temperature -20 to +70 C. Banks needing more stations use 200M-2F through 200M-16F (sixteen maximum), and blank plate kit P-200M-R2 closes unused stations on other 200M orders.
