Airtac 200M Solenoid Valve Base 200M-27F
2、Integrated configuration with centralized air supply/exhaust ports and wiring channels, simplifying troubleshooting and maintenance;
3、Flexible modular design with expandable configuration, allowing seamless addition or rearrangement of connected directional control valves to meet evolving system requirements;
Category: Solenoid Valve Manifold Bases , Brand: AIRTAC , Series: 200M
AirTAC 200M-27F Manifold Base Specifications
- Model: 200M-27F
- Type: Multi-station manifold base for solenoid valve mounting
- Compatible Valves: 200 Series 4V/5V solenoid valves
- Port Configuration: 2/3/5 port options via modular assembly
- Port Size: G1/8 (ISO228 standard)
- Max Operating Pressure: 1.0 MPa
- Temperature Range: -5℃ to 80℃ (with NBR seals)
- Material: Aluminum alloy (A6063-T5) with anodized surface
- Weight: 320g ±5g
- Dimensions: 52mm(L) × 34mm(W) × 80mm(H)
- Surface Roughness: Ra ≤3.2μm (sealing surfaces)
- Mounting Torque: 1.5-2.0 N·m (for M5 mounting screws)
- Leakage Rate: ≤20 cm³/min (under 0.5 MPa)
- Certification: ISO 15407-1 compliant
Precision-machined manifold base enabling centralized control of multiple pneumatic circuits. Features multi-layer sealing design with integrated O-rings (AS568-008 standard) for zero-interference valve clustering. Optimized flow channels reduce pressure drop by 15% compared to conventional manifolds.
- Multi-axis pneumatic actuator synchronization in assembly lines
- Modular control systems for packaging machinery
- Centralized pneumatic control cabinets
- Robotic end-effector tool changers
- Semiconductor manufacturing equipment
Installation protocol:
Clean all port surfaces with IPA before assembly. Use staggered tightening sequence
(50% torque → 80% → 100%) for multi-valve installations. Maintain ambient humidity
below 70% RH during commissioning.
| Property | Property Value |
|---|---|
| sku | 200M-27F |
