Airtac 200M Solenoid Valve Base 200M-3F
Genuine AirTAC valve manifold, order code 200M-3F from the 4AM range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Manifold200M (for 4A200)
- Stations3 stations
- ThreadPT
- Models100M / 200M / 300M / 400M
- For valves4A100 / 4A200 / 4A300 / 4A400
- Maximum stations16 / 16 / 12 / 8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 200M Solenoid Valve Base 200M-3F
Three 4A200 valves bolt onto this AirTAC 200M base so they draw air from one 1/4 inch supply port P and share a common exhaust. That single-point feed cuts pipe runs, saves cabinet width and makes faults easier to trace because every valve sits in one visible row.
The 200M-3F order covers the manifold body, seals and screws; the valves themselves are ordered separately. Feed the bank with air filtered to 40 um and it will operate from -20 to +70 C. If a station is left without a valve during build-up, close it with the P-200M-R2 blank plate kit rather than leaving it open.
Airtac 200M Solenoid Valve Base 200M-3F Technical Specifications
| Order code | 200M-3F |
|---|---|
| Product | Valve Manifold |
| Manifold | 200M (for 4A200) |
| Stations | 3 stations |
| Thread | PT |
| Models | 100M / 200M / 300M / 400M |
|---|---|
| For valves | 4A100 / 4A200 / 4A300 / 4A400 |
| Maximum stations | 16 / 16 / 12 / 8 |
| Supply port P | 1/4" / 1/4" / 3/8" / 1/2" |
| Length A | 100M 38 + 19 × (n-1) mm; 200M 44 + 23 × (n-1) mm; 300M 52 + 28 × (n-1) mm; 400M 61 + 35 × (n-1) mm |
| Fluid | Air, filtered to 40 µm |
| Temperature | -20 to +70 °C |
| Included | Manifold, seals and screws |
| Blank plate | Kit P-□00M-R2 (separate) |
Source: AirTAC 4A manifold datasheet (p.124), ordering code, specifications and dimensions.
How to choose
200M is the manifold that matches 4A200 valves only. The smaller 100M serves 4A100 valves, 300M serves 4A300 through a 3/8 inch supply port, and 400M serves 4A400 through 1/2 inch, so confirm your valve size before ordering. Within the 200M range this 3F code is the right choice when exactly three stations are needed; 2F leaves no headroom and 4F adds another 23 mm of length per valve. Thread is PT because the code carries no G or T suffix.
Applications
Three-gripper pick station
A robot end-of-arm group of three 4A200 valves driving gripper cylinders runs off one 1/4 inch supply, so one FRL set and one shut-off serve all three functions.
Carton sealing head
Flap fold, press and tape-cut cylinders each get a 4A200 valve on the shared bank, keeping the sealing head wiring-free and compact.
Machine cabinet tidy-up
Replacing three individually plumbed 4A200 valves with a 90 mm long 3F manifold frees panel space and gives maintenance one row to inspect.
FAQ
Which valves fit the AirTAC 200M-3F and what are its key figures?
It carries three 4A200 valves on a 200M manifold. Supply port P is 1/4 inch, the thread is PT, and length A is 90 mm (44 mm for the first station plus 23 mm for each additional one). It runs on air filtered to 40 um between -20 and +70 C.
What does the plain PT code mean and what arrives with the manifold?
The order code ends without G or T, so ports are PT threaded. The delivery includes the manifold, seals and screws. Valves, plus a P-200M-R2 blank plate kit for any station without a valve, are ordered separately.
