Airtac 200M Solenoid Valve Base 200M-5F
Genuine AirTAC valve manifold, order code 200M-5F from the 4AM range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Manifold200M (for 4A200)
- Stations5 stations
- ThreadPT
- Models100M / 200M / 300M / 400M
- For valves4A100 / 4A200 / 4A300 / 4A400
- Maximum stations16 / 16 / 12 / 8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 200M Solenoid Valve Base 200M-5F
Five 4A200 valves mounted on this 200M base span 136 mm, calculated as 44 mm for the first station plus 23 mm for each of the four further valves. Because supply and exhaust are common to the whole bank, one 1/4 inch port P feeds all five stations and the group can be vented with a single valve.
The manifold, seals and screws arrive together in the 200M-5F order; valves are added from the 4A200 range separately. Air reaching the stations must be filtered to 40 um, and the working temperature window is -20 to +70 C. A station awaiting its valve is closed off with the P-200M-R2 blank plate kit, which is ordered on its own.
Airtac 200M Solenoid Valve Base 200M-5F Technical Specifications
| Order code | 200M-5F |
|---|---|
| Product | Valve Manifold |
| Manifold | 200M (for 4A200) |
| Stations | 5 stations |
| Thread | PT |
| Models | 100M / 200M / 300M / 400M |
|---|---|
| For valves | 4A100 / 4A200 / 4A300 / 4A400 |
| Maximum stations | 16 / 16 / 12 / 8 |
| Supply port P | 1/4" / 1/4" / 3/8" / 1/2" |
| Length A | 100M 38 + 19 × (n-1) mm; 200M 44 + 23 × (n-1) mm; 300M 52 + 28 × (n-1) mm; 400M 61 + 35 × (n-1) mm |
| Fluid | Air, filtered to 40 µm |
| Temperature | -20 to +70 °C |
| Included | Manifold, seals and screws |
| Blank plate | Kit P-□00M-R2 (separate) |
Source: AirTAC 4A manifold datasheet (p.124), ordering code, specifications and dimensions.
How to choose
This code only fits 4A200 valves; for 4A100, 4A300 or 4A400 valves the matching manifolds are 100M, 300M and 400M, and note that 300M raises the supply port to 3/8 inch while 400M uses 1/2 inch. Among station counts, 4F would be one valve short and 6F would add 23 mm of unused length if only five valves are planned, so 5F is the exact-fit choice. Ports are PT because the order code has no G or T ending, and the 200M family tops out at 16 stations if the bank ever needs to grow.
Applications
Palletiser corner module
Grip, clamp, push, hold and release functions at a palletiser corner all run on 4A200 valves grouped on one 136 mm bank.
Multi-head assembly fixture
Five pressing or inserting cylinders on a fixture share the single 1/4 inch supply, replacing five separate valve installations with one row.
Sortation gate control
Chute gates at five sorting positions take their 4A200 valves from a common manifold, so one air drop and one exhaust path serve the whole sorter section.
FAQ
Which figures define the AirTAC 200M-5F?
Five stations for 4A200 valves, supply port P 1/4 inch, PT threads, and length A of 136 mm (44 mm for station one plus 23 mm per extra station). Fluid is air filtered to 40 um and the temperature range is -20 to +70 C.
What happens to a station that has no valve fitted?
Close it with the P-200M-R2 blank plate kit, sold separately from the manifold order. The 200M-5F package itself contains the manifold, seals and screws only, and the 200M series allows up to 16 stations if the bank is expanded later.
