Airtac 200M Solenoid Valve Base 200M-9F
Genuine AirTAC valve manifold, order code 200M-9F from the 4AM range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Manifold200M (for 4A200)
- Stations9 stations
- ThreadPT
- Models100M / 200M / 300M / 400M
- For valves4A100 / 4A200 / 4A300 / 4A400
- Maximum stations16 / 16 / 12 / 8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 200M Solenoid Valve Base 200M-9F
The 200M-9F order code specifies an AirTAC 200M manifold configured with nine stations and PT threads. It takes nine 4A200 air-piloted valves and joins them into one bank that shares a common supply and exhaust, so nine separate valve feeds collapse into a single 1/4 inch supply port P and one exhaust path.
Each additional station adds 23 mm of manifold length, giving a 228 mm overall Length A for the nine-station bank (44 mm for the first station plus 23 mm per extra station). The order covers the manifold body, seals and screws; close any spare station with the P-200M-R2 blank plate kit, ordered separately.
Airtac 200M Solenoid Valve Base 200M-9F Technical Specifications
| Order code | 200M-9F |
|---|---|
| Product | Valve Manifold |
| Manifold | 200M (for 4A200) |
| Stations | 9 stations |
| Thread | PT |
| Models | 100M / 200M / 300M / 400M |
|---|---|
| For valves | 4A100 / 4A200 / 4A300 / 4A400 |
| Maximum stations | 16 / 16 / 12 / 8 |
| Supply port P | 1/4" / 1/4" / 3/8" / 1/2" |
| Length A | 100M 38 + 19 × (n-1) mm; 200M 44 + 23 × (n-1) mm; 300M 52 + 28 × (n-1) mm; 400M 61 + 35 × (n-1) mm |
| Fluid | Air, filtered to 40 µm |
| Temperature | -20 to +70 °C |
| Included | Manifold, seals and screws |
| Blank plate | Kit P-□00M-R2 (separate) |
Source: AirTAC 4A manifold datasheet (p.124), ordering code, specifications and dimensions.
How to choose
The 200M body fits only 4A200 valves; if your valves are 4A100, 4A300 or 4A400, step to the 100M, 300M or 400M manifold instead. Within the 200M family, 8F covers eight valves and 10F covers ten, so 9F is the match for exactly nine; the capacity ceiling is 16 stations. Thread is PT as standard - a G or T suffix would switch this to G or NPT. Since 200M shares the 1/4 inch supply port with 100M but uses a 23 mm-per-station pitch versus 19 mm, plan panel space for the 228 mm bank.
Applications
Multi-zone conveyor control
A nine-station bank drives nine 4A200 valves governing cylinder-actuated stops, gates and diverters along one conveyor line from a single 1/4 inch supply.
Compact machine valve banks
Machine builders mounting nine directional valves on a confined panel save tubing by sharing one supply and exhaust across the 228 mm long manifold.
Pneumatic circuit consolidation
Retrofit panels where nine scattered individual valves are regrouped onto one base make leaks and faults easier to trace station by station.
FAQ
What are the key figures of the AirTAC 200M-9F manifold?
It is a 200M manifold for nine 4A200 valves with PT threads, a 1/4 inch supply port P and Length A of 228 mm (44 mm + 23 mm x 8). Maximum stations for 200M is 16, air must be filtered to 40 um, working temperature is -20 to +70 C, and the order includes the manifold, seals and screws.
What if I need fewer or more than nine 4A200 valves later?
The 200M family accepts up to 16 stations, so a bank can grow beyond nine. Any station not yet fitted must be closed with the P-200M-R2 blank plate kit, which is ordered separately from the manifold.
