Airtac 2JS Angle Seat Valve 2JSK15015Q50G
$132.57
Regular price
$140.07
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
2JSK15015Q50G
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Pneumatic-controlled operation enables safe deployment in explosive environments and non-electrical applications. Features low actuation pressure requirements for reliable low-pressure control over high-pressure systems.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
Installation note:
Install with actuator positioned above horizontal pipelines.
Requires 100μm filtration for pneumatic supply.
Manual override available via 6mm hex key (emergency operation).
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JSK15015Q50G Angle Seat Valve Specifications
- Model: 2JSK15015Q50G
- Type: 2-way normally open (pneumatic actuation)
- Port size: G1-1/2 (ISO228/1 standard)
- Operating pressure: 0.15–1.0 MPa
- Fluid temperature: -10℃ to 180℃
- Actuation pressure: 0.3–0.8 MPa
- Voltage options: Not applicable (pneumatic control)
- Body material: CF8M stainless steel (AISI 316 equivalent)
- Seal material: PTFE + EPDM composite
- Flow coefficient (Cv): 15.5
- Response time: ≤0.3s (full stroke)
- Weight: 2.8 kg (with actuator)
- Dimensions: 198mm(L) × 135mm(W) × 165mm(H)
- Protection rating: IP67 (actuator), IP65 (valve body)
- Mounting orientation: Horizontal pipeline recommended
Heavy-duty angle seat valve with 90° flow path design, optimized for high-temperature and corrosive media control. Features bubble-tight shut-off (Class VI leakage) and zero-pressure differential activation. The stainless steel construction withstands steam sterilization cycles (SIP/CIP compatible).
Typical Applications:
- Steam line control in food processing plants
- Chemical dosing systems with aggressive media
- High-temperature water circulation in breweries
- Pharmaceutical CIP/SIP processes
- Wastewater treatment plant sludge control
Installation note:
Install with actuator positioned above horizontal pipelines.
Requires 100μm filtration for pneumatic supply.
Manual override available via 6mm hex key (emergency operation).
Service Interval:
- Lubricate actuator piston every 500,000 cycles
- Replace seal kit after 2 million cycles or 3 years
- Inspect valve seat annually in abrasive media applications
| Property | Property Value |
|---|---|
| sku | 2JSK15015Q50G |
| Port Size | G1/2 |
| Flow Aperture | <15mm> |
