Airtac 2JW Angle Seat Valve 2JW15010Q50G
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JW15010Q50G Angle Seat Valve Specifications
- Model: 2JW15010Q50G
- Type: 2/2-way normally closed (pneumatic actuation)
- Port connection: G1/2" female thread (ISO228/1 standard)
- Valve orifice: Ø10mm (optimized flow path design)
- Operating pressure: 0.15–1.0 MPa (21.7–145 psi)
- Actuation pressure: ≥0.15 MPa (21.7 psi)
- Temperature range: -10℃ to 150℃ (medium)/ -20℃ to 80℃ (ambient)
- Seal material: PTFE + EPDM composite (FDA compliant)
- Body material: Stainless steel CF8M (AISI 316)
- Flow rate: 2200 l/min (Cv=3.2 at 7 bar)
- Response time: ≤0.3s (full stroke operation)
- Weight: 980g ±2% (including mounting accessories)
- Dimensions: 158mm(L) × 90mm(W) × 125mm(H) (actuator included)
- Protection rating: IP67 (dust/immersion proof)
- Certifications: RoHS, REACH, ISO 5211 mounting standard
Heavy-duty angle seat valve with 90° flow path design for aggressive media control. Features zero-leakage PTFE bellows seal and thermal shock resistance. The stainless steel body withstands corrosive environments including steam, acids, and alkaline solutions. Requires 40μm filtered air supply with max 5% relative humidity.
- Steam sterilization systems in pharmaceutical equipment
- High-temperature CIP/SIP processes in food & beverage lines
- Chemical dosing systems with aggressive solvents
- Water treatment plant backwash control
- Boiler feed water isolation
Installation note:
Mount with actuator oriented vertically upward. Use PTFE thread sealant
on connections. Perform monthly stem lubrication with silicone-free grease
(ISO 6743-4 classification). Allow 20mm clearance for stem maintenance.
| Property | Property Value |
|---|---|
| sku | 2JW15010Q50G |
| Port Size | G3/8 |
| Flow Aperture | <15mm> |
