Airtac 2KL Solenoid Valve 2KL03006BI
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
AirTAC 2KL03006BI 5/2-Way Solenoid Valve Specifications
- Model: 2KL03006BI
- Type: 5/2-way double solenoid (dual coil)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC12V, DC24V, AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 1200 NL/min (ANR)
- Weight: 350g ±5% (including coils)
- Dimensions: 80mm(L) × 45mm(W) × 65mm(H)
- Core material: Stainless steel plunger with PTFE coating
- Seal material: Heat-resistant NBR (option: FKM/Viton)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Power consumption: 3W (DC), 4.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (coils), IP40 (valve body)
- Mounting type: ISO 5599-1 standard sub-base compatible
High-flow bistable solenoid valve with latching function, designed for energy-efficient operation in industrial automation. Features manual override button for system debugging and a dust-resistant pilot mechanism. Optimized for systems requiring position hold without continuous power consumption.
- Pneumatic cylinder control in assembly lines
- Textile machinery clamping systems
- Plastic injection molding machine actuators
- Automated warehouse stacker controls
- Battery production line tooling fixtures
Installation best practices:
Use anti-vibration mounting brackets in high-cycle applications (>1Hz).
Maintain air quality with 5μm filter + 0.1mg/m³ oil mist content.
For horizontal mounting, install coil connectors facing upward.
| Property | Property Value |
|---|---|
| sku | 2KL03006BI |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
