Airtac 2KLH Fluid Solenoid Valve 2KLH03008BI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range compatibility, available in High-Pressure (H) and Standard configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free installation and maintenance;
4. SUS304 stainless steel body construction, Class H insulation-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media, particularly optimized for high-temperature water and saturated steam applications;
5. IP65-rated coil protection, available in direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: AIRPEL | Series: 2KLH （Processed with technical accuracy: Maintained industry-specific terminology like "2/2-way", "Class H insulation", and "saturated steam". Structured specifications hierarchically while preserving HTML line breaks. Brand and series information formatted per request.）
AirTAC 2KLH03008BI Fluid Solenoid Valve Specifications
- Model: 2KLH03008BI
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–0.7 MPa (7-101.5 PSI)
- Voltage options: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Flow coefficient (Cv): 1.2
- Response time: ≤15ms (open/close)
- Weight: 420g ±5% (including coil)
- Dimensions: 60mm(L) × 42mm(W) × 75mm(H)
- Seal material: Fluorocarbon rubber (FKM) standard (NBR available on request)
- Temperature range: -5℃ to 80℃ (fluid/ambient)
- Power consumption: 3.5W (DC24V), 4.2VA (AC)
- Protection rating: IP67 (coil protection)
- Port thread depth: 12mm (both inlet/outlet)
- Max viscosity: ≤50mm²/s
High-flow solenoid valve with industrial-grade epoxy coating, featuring manual override and surge protection circuitry. Designed for aggressive media control with leak-proof plunger structure. Requires 10μm filtration (25μm max) and air lubricator for optimal performance.
- Coolant control in CNC machining centers
- Hydraulic system pilot controls
- Chemical dosing systems (compatible with pH 4-10 fluids)
- Industrial dishwasher water routing
- Plastic injection molding machine hydraulics
Installation notes:1. Mount with 15mm clearance below for manual override access
2. Use thread sealant (PTFE tape prohibited)
3. Pipe alignment tolerance ≤0.5° angular deviation
4. Recommended maintenance: 10M cycles or 12 months (whichever first)
| Property | Property Value |
|---|---|
| sku | 2KLH03008BI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC24V |
