Airtac 2KLH Fluid Solenoid Valve 2KLH05010FI
2. Wide pressure range compatibility, available in High-Pressure (H) and Standard configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free installation and maintenance;
4. SUS304 stainless steel body construction, Class H insulation-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media, particularly optimized for high-temperature water and saturated steam applications;
5. IP65-rated coil protection, available in direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: AIRPEL | Series: 2KLH （Processed with technical accuracy: Maintained industry-specific terminology like "2/2-way", "Class H insulation", and "saturated steam". Structured specifications hierarchically while preserving HTML line breaks. Brand and series information formatted per request.）
AirTAC 2KLH05010FI Fluid Solenoid Valve Technical Details
- Model: 2KLH05010FI
- Type: 2-position 5-port direct-acting (double solenoid)
- Port configuration: 5/2-way
- Port thread: G1/8 (BSPP) with optional NPT1/8 adapter
- Operating pressure: 0.05–1.0 MPa (7–145 PSI)
- Max flow rate: 750 L/min (Cv=1.3 at 0.5 MPa)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 2.2VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Seal material: FKM (Viton) fluorocarbon rubber
- Body material: Anodized aluminum alloy (ISO-AlSi10Mg)
- Ambient temperature: -10℃ to 60℃ (with anti-freeze measures below 0℃)
- Fluid temperature: 0℃ to 60℃
- Protection class: IP67 (dustproof & temporary immersion)
- Weight: 0.68 kg ±5% (including connectors)
- Dimensions: 76mm(L) × 34mm(W) × 83mm(H) (manual override protrusion adds 12mm)
- Port spacing: 18mm between adjacent ports
- Electrical connection: DIN43650 Form C connector with LED indicator
High-flow bistable valve with dual coil redundancy, designed for aggressive duty cycles in industrial automation. Features dual manual override buttons with position lock mechanism and status indication window. Requires 25μm filtration with oil mist lubrication (ISO 8573-1:2010 Class 4.4.3). Compatible with compressed air, inert gases, and light hydraulic fluids (ISO VG32 or thinner).
- Plastic injection molding machine clamp control
- CNC tool changer actuator sequencing
- Automotive test bench pneumatic simulation
- Beverage filling line pressure regulation
- Semiconductor wafer handling vacuum/pressure switching
Installation protocol:
Mount with vibration-damping brackets in horizontal orientation.
Maintain 20mm clearance below valve for condensate drainage.
Perform quarterly lubrication via designated grease ports (use PAG-based lubricant).
| Property | Property Value |
|---|---|
| sku | 2KLH05010FI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
