Airtac 2KS Series Fluid Control Valve 2KS05010BI
2、Wide pressure range compatibility with specialized configurations: Ultra-High Pressure (X), High Pressure (H), Standard, and High Flow (L) variants;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation/maintenance capabilities;
4、SUS304 stainless steel body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with diverse media. Custom sealing materials available through technical consultation;
5、IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KS
AirTAC 2KS05010BI Fluid Control Valve Technical Specifications
- Model: 2KS05010BI
- Valve type: 2-position 5-way pilot-operated
- Port configuration: 5 ports (P, A, B, EA, EB)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–0.8 MPa
- Max flow rate: 1,200 NL/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Seal material: HNBR (Hydrogenated Nitrile) for high oil resistance
- Body material: Aluminum alloy (anodized surface)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Response time: ≤50ms (at 0.5MPa)
- Weight: 520g ±5%
- Dimensions: 118mm(L) × 52mm(W) × 38mm(H)
- Protection rating: IP67 (dustproof & temporary immersion)
- Mounting orientation: Any (horizontal/vertical)
- Manual override: Built-in emergency switch
High-flow directional control valve with optimized spool geometry for reduced pressure drop. Features dual exhaust ports (EA/EB) for speed regulation and shock absorption. The hardened stainless steel shaft prevents wear in high-cycle applications (>5 million cycles). Compatible with ISO 15407-1 standards.
- Automated assembly line cylinder sequencing
- Plastic injection molding machine clamp control
- CNC tool changer positioning systems
- Food processing pneumatic actuators (oil-mist lubricated environments)
- Semiconductor wafer handling robotics
Installation guidelines:
Use M5 mounting screws with 0.49–0.69N·m torque. Maintain 0.5m minimum
distance from high-frequency inverters. Lubricate with ISO VG32 turbine oil
if used in dry conditions. Replace seals every 20,000 operating hours.
Critical note:
Requires 5μm filtration (40μm for lubricated systems). Do NOT use with
phosphate ester-based fluids. Allow 15-minute cool-down after continuous
8-hour operation at maximum pressure.
| Property | Property Value |
|---|---|
| sku | 2KS05010BI |
| Port Size | PT3/8 |
| Flow Aperture | PT3/8 |
| Coil Voltage | DC24V |
