Airtac 2KS Series Fluid Control Valve 2KS05010EI
2、Wide pressure range compatibility with specialized configurations: Ultra-High Pressure (X), High Pressure (H), Standard, and High Flow (L) variants;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation/maintenance capabilities;
4、SUS304 stainless steel body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with diverse media. Custom sealing materials available through technical consultation;
5、IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KS
AirTAC 2KS Series Fluid Control Valve 2KS05010EI Technical Details
- Model: 2KS05010EI
- Type: 5-port 3-position closed center (ISO 5599-1 compliant)
- Port configuration: G1/2" (BSPP thread)
- Operating pressure range: 0.1–1.0 MPa
- Max flow rate: 1,200 NL/min (ANR)
- Voltage variants: DC24V (±10%), AC110V 50/60Hz, AC220V 50Hz
- Coil insulation class: Class F (155℃)
- Response time: ≤35ms (at 0.5MPa)
- Body material: Aluminum alloy with hard anodized finish
- Seal compounds: HNBR (Hydrogenated Nitrile) standard, optional FKM
- Ambient temperature range: -5℃ to 80℃
- Fluid temperature range: 0℃ to 60℃
- Protection class: IP67 (coil), IP40 (valve body)
- Weight: 450g ±5% (excluding accessories)
- Dimensions: 80mm(L) × 50mm(W) × 60mm(H)
- Manual override: Optional paddle-type actuator
- Mounting style: Direct mounting with ISO 4401 interface
High-flow proportional control valve engineered for industrial automation systems requiring precise directional control. Features dual-pressure operation capability and shock-resistant design with integrated silencer (optional). The EI suffix indicates enhanced ingress protection and EMI-shielded coil construction. Requires 5μm filtration with automatic drain.
- Plastic injection molding machine clamp control
- Automotive assembly line pneumatic actuators
- Beverage filling station manifold systems
- Semiconductor wafer handling robotics
- Hydraulic system pilot stage control
Operational guidance:
Maintain 0.3-0.5 MPa lubrication pressure when using oil mist lubrication.
For horizontal installation, use support bracket P/N BR-2KS50.
Perform monthly stem seal inspection in high-cycling applications (>500,000 cycles/month).
| Property | Property Value |
|---|---|
| sku | 2KS05010EI |
| Port Size | PT3/8 |
| Flow Aperture | PT3/8 |
| Coil Voltage | AC24V |
