Airtac 2KSH Fluid Control Valve 2KSH03006F
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH03006F Fluid Control Valve Specifications
- Model: 2KSH03006F
- Type: 5/2-way solenoid valve (double solenoid)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.1–0.8 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.8
- Response time: ≤30ms (exhaust to actuation)
- Weight: 350g ±5%
- Dimensions: 56mm(L) × 42mm(W) × 76mm(H)
- Seal material: NBR (Nitrile) standard / FKM (Fluorocarbon) optional
- Temperature range: -20℃ to 80℃ (with FKM seals: -10℃ to 150℃)
- Protection rating: IP67 (dustproof and waterproof immersion up to 1m)
- Port thread depth: 10mm (minimum engagement)
- Max operating cycles: 50 million (under standard conditions)
High-flow directional control valve with dual solenoid operation, featuring a reinforced aluminum alloy body and corrosion-resistant plating. Designed for precise bi-directional flow control in automated systems, with integrated manual override and LED status indicator. Requires 5μm filtered compressed air with lubrication (ISO 8573-1:2010 Class 4.4.3).
- Automated production line actuators
- Plastic injection molding machine controls
- Pneumatic clamping systems
- Textile machinery sequencing
- Automotive assembly robotics
- Bottle filling/capping systems
Installation note:
Mount with vibration-damping pads in high-frequency environments.
Maintain minimum 15mm clearance around exhaust ports.
Use copper-free anti-seize compound on threads.
Cycle valve 3-5 times manually after long-term storage.
| Property | Property Value |
|---|---|
| sku | 2KSH03006F |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
