Airtac 2KSH Fluid Control Valve 2KSH03008B
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH03008B Technical Specifications
- Model: 2KSH03008B
- Type: 3-position, 5-way (double solenoid)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5%
- Dimensions: 78mm(L) × 42mm(W) × 39mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -20℃ to 80℃ (non-freezing)
- Flow capacity: 500 L/min (ANR) at 0.5MPa
- Response time: ≤20ms (electrical), ≤50ms (mechanical)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (full engagement recommended)
High-flow directional control valve with dual electromagnetic operation, featuring low-hysteresis spool movement and pressure-balanced design. The hardened aluminum alloy body with micro-arc oxidation treatment ensures corrosion resistance in humid environments. Includes manual override and position detection switch compatibility.
- Automated production line cylinder sequencing
- Plastic injection molding machine clamp control
- CNC tool changers with position feedback
- High-cycle packaging equipment (200+ operations/minute)
- Cleanroom automation with ISO Class 6 compliance
Installation guidelines:
Mount horizontally with actuator ports downward. Use M5 mounting screws with 0.6-0.8Nm torque.
Maintain 0.5-1.0mm clearance between manifold surfaces. Pre-charge system with dry air
(pressure dew point -20℃) before initial activation.
| Property | Property Value |
|---|---|
| sku | 2KSH03008B |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC24V |
