Airtac 2KSL Fluid Control Valve 2KSL03006EI
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL03006EI Fluid Control Valve Specifications
- Model: 2KSL03006EI
- Type: 5/2-way solenoid valve (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 psi)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5g (without connectors)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (fluid temperature)
- Power consumption: 2.5W (DC24V), 4.5VA (AC)
- Response time: Opening ≤20ms / Closing ≤15ms
- Flow characteristics: Cv=0.25 (Kv=0.22)
- Protection rating: IP65 (coil part)
- Port thread depth: 12mm (minimum engagement)
- Max operating frequency: 5Hz (with 50% duty cycle)
High-performance 5-port directional control valve featuring dual solenoid operation with manual override. Engineered for precision fluid control in automated systems, its aluminum alloy body provides excellent heat dissipation and corrosion resistance. The low-hysteresis design ensures stable switching even under variable pressure conditions. Requires ISO 8573-1:2010 Class 3 compressed air (max 5μm particle size).
- Pneumatic cylinder sequencing in assembly lines
- Automated packaging machinery double-acting actuators
- Textile production air circuit control
- Automotive brake system testing rigs
- Food processing equipment with clean air requirements
Installation guidelines:
Mount on vibration-free surfaces using M4 mounting screws (torque ≤0.8N·m).
Maintain minimum 15mm clearance around exhaust ports. Lubricate with ISO VG32
turbine oil if used in high-cycle applications (>1 million operations/year).
| Property | Property Value |
|---|---|
| sku | 2KSL03006EI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
