Airtac 2KSL Fluid Control Valve 2KSL03006FI
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL Fluid Control Valve 2KSL03006FI Technical Details
- Model: 2KSL03006FI
- Type: 3-position, 5-way closed center (pneumatic pilot operated)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.2–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 1.25 kg ±5% (including coil)
- Dimensions: 105mm(L) × 54mm(W) × 78mm(H)
- Seal materials: HNBR (Hydrogenated Nitrile) with PTFE backup rings
- Temperature tolerance: -10℃ to 80℃ (with silicone seals optional for -20℃ operation)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Response time: ≤30ms (at 0.5MPa)
- Flow capacity: 750 L/min (ANR)
- Port thread depth: 12mm (minimum engagement)
- Protection class: IP67 (coil), IP40 (valve body)
High-flow proportional control valve with center-block function, featuring brass main body with hard anodized aluminum pilot section. Designed for precision mid-stroke positioning in pneumatic systems, with integrated manual override and LED status indicator. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Robotic arm clamping force modulation
- Plastic injection molding machine sequence control
- Automated assembly line pallet positioning
- Textile machinery tension regulation systems
- Semiconductor wafer handling vacuum/pressure switching
Installation guidelines:
Mount horizontally with pilot valves facing downward to prevent debris accumulation.
Use vibration-damping brackets in high-cycle applications (>1.5 million operations/year).
Maintain 20mm clearance around exhaust ports for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 2KSL03006FI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
