Airtac 2KSL Fluid Control Valve 2KSL03008BI
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL Series Fluid Control Valve 2KSL03008BI Technical Details
- Model: 2KSL03008BI
- Type: 3-position, 5-way closed center (double solenoid)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 L/min (ANR) at 0.5 MPa
- Response time: ≤25ms (excitation), ≤35ms (reset)
- Weight: 320g ±5% (excluding connectors)
- Dimensions: 80mm(L) × 45mm(W) × 65mm(H)
- Seal materials: HNBR main seals with FKM backup rings
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.5W (DC models), 4.5VA (AC models)
- Port thread depth: 10mm (minimum engagement)
- Protection class: IP67 (coil), IP40 (valve body)
- Hysteresis: ≤10% of rated voltage
High-flow proportional control valve with dual solenoid activation, featuring aluminum alloy body with hard anodized treatment for chemical resistance. The center-block design prevents unintended actuator movement during power loss. Integrated LED status indicators and surge protection circuitry ensure reliable operation in electromagnetic interference environments. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Precision positioning systems in semiconductor manufacturing
- Multi-axis robotic gripper pressure regulation
- Plastic injection molding machine clamp control
- Automated assembly line sequencing valves
- Test bench pressure profiling systems
Installation protocol:
Mount on vibration-damped surfaces using M4 mounting screws (not included).
Maintain minimum 15mm clearance below valve for manifold heat dissipation.
Lubricate seals with ISO VG32-grade turbine oil before initial operation.
| Property | Property Value |
|---|---|
| sku | 2KSL03008BI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
