Airtac 2KSL Fluid Control Valve 2KSL03008F
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL Fluid Control Valve 2KSL03008F Technical Specifications
- Model: 2KSL03008F
- Type: 2-position 3-way sliding valve (monostable)
- Port configuration: 3/2-way normally closed
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Maximum flow rate: 750 L/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Valve body material: Aluminum alloy with hard anodized treatment
- Seal material: NBR (Nitrile) standard, optional FKM/Viton for chemical resistance
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Weight: 320g ±5% (including coil)
- Dimensions: 78mm(L) × 34mm(W) × 45mm(H)
- Electrical protection: Class F insulation, surge absorption circuit built-in
- Protection rating: IP67 (coil), IP40 (valve body)
- Manual override: Optional emergency manual operation version
High-flow proportional control valve featuring low hysteresis and zero-point calibration capability. The dual-coil heat dissipation design enables continuous duty cycle operation. Optimized spool geometry reduces pressure loss by 18% compared to previous generation models. Requires 5μm filtration (25μm for temporary use) with oil mist lubrication recommended for extended service life.
- Precision pressure regulation in semiconductor wafer handling systems
- Batch processing control in pharmaceutical liquid dispensing equipment
- Hydraulic system pilot stage control for injection molding machines
- Automated beverage filling line flow modulation
- Pneumatic brake system management in material handling vehicles
- Mount on vibration-isolated surfaces (max. 4.9m/s² acceleration)
- Maintain 50mm clearance below valve for maintenance access
- Use copper-free anti-seize compound on threaded ports
- For horizontal mounting, install exhaust silencer vertically upward
- Ground terminal must connect to ≤100Ω earth resistance
Maintenance cycle:
Perform spool lubrication every 2 million cycles (standard NBR seals)
or 5 million cycles (FKM seals) under normal operating conditions.
| Property | Property Value |
|---|---|
| sku | 2KSL03008F |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
