Airtac 2KSL Fluid Control Valve 2KSL05010AI
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL05010AI Fluid Control Valve Specifications
- Model: 2KSL05010AI
- Type: 5/2-way single solenoid control (spring return)
- Port size: PT1/2 (G1/2 equivalent)
- Operating pressure: 0.2–1.0 MPa
- Flow capacity: 1,200 L/min (Cv=2.2 at 0.5 MPa)
- Voltage options: AC220V±10% 50/60Hz, DC24V±10%
- Power consumption: 3.5W (AC), 4.8W (DC)
- Weight: 520g ±5%
- Dimensions: 118mm(L) × 52mm(W) × 78mm(H)
- Valve body material: Anodized aluminum alloy
- Seal material: Fluorocarbon rubber (FKM)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Response time: ≤30ms (actuation), ≤20ms (reset)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with precision-machined spool mechanism, featuring dual-position exhaust paths for rapid cycling. The hardened stainless steel guide sleeves ensure ≤0.01mm internal leakage. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3 purity. Lubrication-free design supports 10 million cycle lifespan under rated conditions.
- Pneumatic cylinder sequencing in assembly lines
- Vacuum generator control for material handling
- Packaging machine clamp pressure regulation
- Textile machinery air flow distribution
- Semiconductor wafer handling systems
Installation guidelines:
Mount horizontally with arrow alignment to airflow direction.
Use 2mm gap between manifold surfaces. Pre-charge system with
0.3MPa pressure before initial activation. Annual lubrication
of external moving parts recommended.
Compatibility note:
Not suitable for oxygen-enriched atmospheres or aggressive gases
(CO2, NH3). Maximum 80% duty cycle for continuous operation.
| Property | Property Value |
|---|---|
| sku | 2KSL05010AI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
