Airtac 2KSL Fluid Control Valve 2KSL05010EI
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL Fluid Control Valve 2KSL05010EI Technical Details
- Model: 2KSL05010EI
- Type: 3-position, 5-way, closed center (Double solenoid)
- Port size: G1/8 (ISO 228/1 standard)
- Operating pressure: 0.15–1.0 MPa (21.7–145 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.68 kg (1.5 lbs)
- Dimensions: 96mm(L) × 42mm(W) × 85mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (with intermittent operation up to 100℃)
- Flow capacity: 1,200 Nl/min (Cv=1.8)
- Response time: ≤15ms (at rated voltage)
- Protection rating: IP67 (dust tight & protected against immersion)
- Manual override: Built-in mechanical override button
High-performance mid-body valve with double solenoid actuation, featuring zero leakage design and corrosion-resistant aluminum alloy construction. The 3-position configuration allows for precise flow path control with center exhaust function. Requires 5μm filtered compressed air (ISO 8573-1:2010 Class 3) and compatible with ISO 1 lubricants.
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC machine tool chuck controls
- Semiconductor wafer handling robotics
- High-cycle packaging equipment diverters
Installation guidelines:
Mount in vibration-free environment using M4 mounting screws (torque ≤0.8N·m).
Maintain minimum 20mm clearance around exhaust ports. Perform monthly
lubrication via air line lubricator (ISO VG32 oil recommended).
Critical note:
Do NOT use with oxygen or combustible gases. Maximum allowable
switching frequency: 5Hz continuous operation. Always install
downstream pressure regulator when used with vacuum systems.
| Property | Property Value |
|---|---|
| sku | 2KSL05010EI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
