Airtac 2KWH Fluid Solenoid Valve 2KWH03008FI
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH03008FI Fluid Solenoid Valve Technical Profile
- Full model designation: 2KWH03008FI
- Valve configuration: 2-position 3-way normally closed (direct-acting)
- Port threading: G1/8 (BSPP) with metal seal
- Pressure range: 0.05–1.0 MPa (water/oil applications), 0.15–1.0 MPa (air/gas)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow characteristics: Cv=0.08 (water), Kv=0.09 (air)
- Body material: Stainless steel SS304 with electropolished surfaces
- Seal compounds: FKM (Viton®) standard, EPDM optional
- Ambient temp. range: -5℃ to 80℃ (non-freezing conditions)
- Response time: ≤15ms (actuation), ≤20ms (deactivation)
- Electrical protection: Class F insulation, transient voltage suppression
- Weight: 320g ±5% (excluding connectors)
- Compact dimensions: 58mm(L) × 34mm(W) × 42mm(H) (port axis direction as length)
- Ingress protection: IP67 (submersible up to 1m for 30min)
- Certifications: RoHS2, REACH, CE (EMC/LVD)
High-cycle fluid control valve with corrosion-resistant architecture, engineered for aggressive media including compressed air, inert gases, water-glycol mixtures, and light hydraulic oils. Features zero-leakage poppet design with wear-compensating spring mechanism. Requires 25μm filtration upstream (not included). Compatible with pulse-width modulation (PWM) control.
- Coolant flow control in CNC machining centers
- Lubrication system metering in food processing lines
- Vacuum/pressure cycling in semiconductor wafer handling
- Hydraulic pilot stage activation in mobile construction equipment
- Sterile media diversion in pharmaceutical CIP systems
Installation protocol:
Mount with flow arrow aligned to piping direction. For liquid applications,
maintain minimum 200mm straight inlet piping. Perform 50-cycle dry run
before media exposure. Annual diaphragm inspection recommended.
Media restrictions:
Not compatible with ketones, esters, or chlorinated hydrocarbons.
Maximum viscosity: 32 cSt. Particulate contamination voids warranty.
| Property | Property Value |
|---|---|
| sku | 2KWH03008FI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
