Airtac 2KWH Fluid Solenoid Valve 2KWH05010CI
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH05010CI Fluid Solenoid Valve Technical Details
- Model: 2KWH05010CI
- Type: Direct-acting 2-position 2-way (2KWH series)
- Fluid compatibility: Air, Water, Light oils (ISO VG32 or lower)
- Port size: G1/8 (BSPP thread)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Max flow rate: 700 L/min (at 0.5 MPa)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 280g ±5g (with coil)
- Dimensions: 62mm(L) × 38mm(W) × 52mm(H) (excluding connectors)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced chemical resistance
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.2W nominal (DC models), 3.5VA (AC models)
- Protection rating: IP67 (coil), IP65 (valve body)
- Port alignment: Inline configuration with 18mm center-to-center port spacing
High-flow compact solenoid valve featuring a brass body with electroless nickel plating for corrosion resistance. The zero differential pressure operation design allows reliable actuation in low-pressure systems. Optimized flow path geometry reduces pressure drop by 18% compared to previous generation models. Includes manual override button for system debugging.
- Coolant control in CNC machining centers
- Dosing systems for liquid additives in chemical processing
- Hydraulic pilot stage control in mobile machinery
- Reverse osmosis water treatment plants
- Lubrication line management in food-grade equipment
Installation guidelines:
Mount in any orientation except coil-down position. Install downstream
25μm filter when handling non-air media. Cycle valve monthly if used
in intermittent service to prevent seal adhesion. Minimum 20mm clearance
required around coil for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 2KWH05010CI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
