Airtac 2KWL Fluid Solenoid Valve 2KWL03008CI
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL Fluid Solenoid Valve 2KWL03008CI Technical Details
- Model: 2KWL03008CI
- Valve type: 2-position 3-way normally closed (direct-acting)
- Port configuration: 3 ports (P: pressure, A: outlet, R: exhaust)
- Port thread: PT1/4 (G1/4 optional)
- Operating medium: Air, water, light oil (ISO VG32 or lower)
- Pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC24V (±10%), AC220V 50/60Hz
- Power consumption: DC: 2.8W max | AC: 3.5VA max
- Flow coefficient: 1.2 Cv (Kv 1.0)
- Response time: ≤15ms (at 0.5MPa)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced chemical resistance
- Ambient temperature: -5℃ to 80℃ (23°F to 176°F)
- Weight: 520g ±5% (with coil)
- Dimensions: 70mm(L) × 45mm(W) × 100mm(H)
- Protection class: IP67 (coil) / IP40 (valve body)
- Port alignment: Horizontal port configuration standard
High-flow solenoid valve with direct-acting mechanism for precise fluid control in medium-pressure systems. Features anodized aluminum body with brass core components for corrosion resistance in humid environments. Includes manual override button for system debugging. Requires 25μm filtration (50μm max). Compatible with vacuum applications when paired with vacuum-rated seals.
- Beverage filling line liquid control systems
- Coolant circulation control in CNC machining centers
- Automatic car wash water flow sequencing
- Hydraulic pilot controls for agricultural machinery
- Laboratory analytical instrument fluid handling
Installation guidelines:
Mount with flow direction arrow aligned to piping. Allow 20mm clearance below
exhaust port for proper venting. Use pulse-width modulation (PWM) drivers
for DC models to prevent coil overheating during extended operation.
Avoid media containing particles >50μm.
For viscous fluids (>32cSt), install vertically with outlet port downward.
Maximum continuous duty cycle: 90% (AC) / 100% (DC).
| Property | Property Value |
|---|---|
| sku | 2KWL03008CI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
