Airtac 2L Solenoid Valve 2L03006A
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03006A Technical Specifications
- Model: 2L03006A
- Type: 3/2-way normally closed (pilot-operated)
- Port configuration: PT1/8 (G1/8 optional)
- Thread standard: ISO228/1 (BSPP)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 psi)
- Maximum flow rate: 750 l/min (ANR)
- Voltage tolerance: ±10%
- Voltage options:
- DC12V (0.8W)
- DC24V (1.2W)
- AC110V 50/60Hz (2.1VA)
- AC220V 50/60Hz (2.3VA)
- Response time: ≤15ms (at 0.5MPa)
- Weight: 220g ±5% (with connector)
- Dimensions: 60mm(L) × 30mm(W) × 50mm(H)
- Seal material: Heat-resistant NBR (-20℃ to 80℃)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Protection class: IP67 (dust/water resistant)
- Electrical connection: DIN43650 Form A
- Cycle life: ≥10 million operations
High-speed electromagnetic valve with energy-efficient coil design, featuring copper-free aluminum body for corrosion resistance in humid environments. The low-hysteresis plunger mechanism ensures precise flow control with 0.1MPa minimum operating differential pressure. Requires 5μm filtered compressed air with lubrication (ISO8573-1 Class 3).
- Automated assembly line clamping systems
- Textile machinery pneumatic sequencing
- Food-grade packaging equipment (FDA-compliant seals)
- Semiconductor wafer handling robots
- Mobile hydraulic control units
Mounting guidelines:
Install with manifold base using M3×12 screws (1.2N·m torque max).
Maintain ≥15mm clearance from heat sources. For horizontal mounting,
use anti-vibration brackets in high-cycle applications (>5Hz).
Maintenance alert:
Replace desiccant in air prep unit every 800 operational hours.
Lubricate using ISO VG32 turbine oil if operated beyond 50℃ ambient.
| Property | Property Value |
|---|---|
| sku | 2L03006A |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC220V |
