Airtac 2L Solenoid Valve 2L03008FI
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03008FI Technical Details
- Model: 2L03008FI
- Type: 5/2-way double solenoid operated (monostable)
- Port size: PT3/8 (G3/8 thread standard)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (without connector)
- Dimensions: 72mm(L) × 48mm(W) × 105mm(H)
- Port thread depth: 12mm (minimum engagement)
- Seal material: HNBR rubber (high resistance to heat and chemicals)
- Temperature range: -5℃ to 80℃ (no freezing condensation)
- Power consumption: DC: 3.5W max / AC: 4.5VA max
- Response time: ≤15ms (at 0.5MPa)
- Maximum flow: 1200Nl/min (Cv=2.0)
- Protection rating: IP67 (dust tight and protected against temporary immersion)
- Service life: ≥10 million cycles (under rated conditions)
High-flow bistable valve with dual coil configuration for precise directional control in demanding industrial environments. Features anti-vibration design with stainless steel plunger and shock-resistant coil structure. Requires compressed air with ISO 8573-1:2010 Class 3.4.3 purity (max 5mg/m³ oil content). Compatible with ISO 15407-1 standard manifolds.
- Pneumatic cylinder sequencing in automated assembly lines
- Clamping/unclamping systems in CNC machining centers
- Material handling equipment position control
- Plastic injection molding machine actuators
- High-cycle packaging machinery (e.g., carton sealing systems)
Installation guidelines:
Mount in any orientation except coil-down position. Maintain minimum 20mm clearance around coils for heat dissipation. Use copper-free lubricants if needed. For parallel manifold installation, apply 0.49-0.98Nm torque on mounting screws.
Critical note:
Always install downstream pressure regulator and 5μm filter. Avoid rapid cycling (>5Hz) without proper heat sink. Not suitable for explosive atmospheres (non-Ex version).
| Property | Property Value |
|---|---|
| sku | 2L03008FI |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC12V |
