Airtac 2L Solenoid Valve 2L05010BI
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L05010BI Technical Details
- Model: 2L05010BI
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V, DC24V, AC110V, AC220V (±10%)
- Manual override: Built-in emergency switch
- Weight: 220g ±5g (without connectors)
- Dimensions: 55mm(L) × 32mm(W) × 72mm(H)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature tolerance: -5℃ to 80℃ (non-freezing)
- Power consumption: ≤2.2W (DC)/≤3.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Port thread depth: 10mm (4-wrap sealing)
- Protection class: IP67 (dust/water resistant)
- Service life: 50 million cycles (minimum)
High-flow directional control valve engineered for industrial automation sequences. Features pilot-assisted operation for low energy consumption (0.15W standby mode) and integrated surge suppression. Requires ISO 8573-1:2010 Class 3.4.3 compressed air (max 5μm particle size). Compatible with vacuum applications down to -95kPa.
- Robotic arm end-effector controls
- Plastic injection molding machine clamp units
- CNC tool changer mechanisms
- Textile machinery pneumatic circuits
- Automated assembly line actuators
- Semiconductor wafer handling systems
Mounting protocol:
Install with vibration-damping brackets in high-shock environments.
Maintain 15mm clearance below valve for condensate drainage.
Use copper-free anti-seize compound on threads.
| Property | Property Value |
|---|---|
| sku | 2L05010BI |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC24V |
